Item(s) for Sale:
TC Sounds OEM 6.5" mids
Item(s) Description/Condition:
New. They've been tested for T/S specs.
2.875" deep
These are made to run IB in a door. I'm actually sad to sell them since I never got a different car to put a system in.
T/S Specs:
Mid 1:
Re = 3.3498 ohms
Fs = 92.2571 Hz
Zmax = 15.5671 ohms
Qes = 1.2390
Qms = 4.5187
Qts = 0.9724
Le = 0.3441 mH (at 1 kHz)
Diam = 165.1000 mm (6.5000 in)
Sd = 21408.3884 mm^2(33.1831 in^2)
Vas = 13.5196 L (0.4774 ft^3)
BL = 4.7394 N/A
Mms = 14.3321 g
Cms = 207.6493 uM/N
Kms = 4815.8120 N/M
Rms = 1.8385 R mechanical
Efficiency = 0.8051 %
Sensitivity = 91.0764 dB @1W/1m
Sensitivity = 94.8571 dB @2.83Vrms/1m
Mid 2:
Re = 3.3800 ohms
Fs = 95.1693 Hz
Zmax = 17.7092 ohms
Qes = 1.2411
Qms = 5.2613
Qts = 1.0042
Le = 0.3542 mH (at 1 kHz)
Diam = 165.1000 mm (6.5000 in)
Sd = 21408.3884 mm^2 ( 33.1831 in^2)
Vas = 13.3284 L (0.4707 ft^3)
BL = 4.7169 N/A
Mms = 13.6616 g
Cms = 204.7125 uM/N
Kms = 4884.8989 N/M
Rms = 1.5527 R mechanical
Efficiency = 0.8698 %
Sensitivity = 91.4122 dB @1W/1m
Sensitivity = 95.1539 dB @2.83Vrms/1m
Price:
$130 shipped
Item Pictures:
