No trades please maybe partial on the motor. Basket is not for sale. I only can take money orders no paypal sorry. Usps is the easiest to send a money order since i can ship and cash at the same time.

Tc made 4hp motor-$315 shipped

Sundown E8s Pending

Tc Sounds 3" qca ring $25 shipped?

specs on e8s

Re = 3.37 ohms (4 ohm nominal)

Fs = 34.9 hz

Qes = 0.5323

Qms = 6.93

Qts = 0.4943

Vas = 7.6 L

BL = 13.3 N/A

Mms = 127.7 grams

Cms = 162 um/N

Xmax = 12mm one-way linear (70% BL method)

Rated RMS Power = 200 watts

Depth = 4.25"

OD w/ gasket = 8 5/16"

Cut Out = 7"



Sealed Box:

0.280 ft^3 w/ F3 of 50 Hz (Qtc = 0.707)



Ported Box:

0.60 ft^3 tuned to 30 Hz

F3 of 25 Hz

E8's









Qca Ring





4hp motor







comes with magnet boot


what the hell isa qca ring?
QCA = Quick Change Assembly.

This is the female half that mounts to the basket of the driver. The motor has the male half mounted to it, allowing the two to be screwed together. This facilitates replacement if the top assembly is damaged.
