Fs planet audio 3 way electronic crossover ec20b

[momofx 10+ year member]

Item(s) for Sale:

Planet Audio 3 Way Electronic Crossover EC20B

Item(s) Description/Condition:

Item is lightly used but in excellent cosmetic and working condition. Comes complete with Bass level controller and its wiring which is still new / never used.

Product Features

•Planet Audio 3-way Electronic Crossover

•Remote subwoofer level control

•Independent front, rear and subwoofer level controls

•DC to DC power supply

•Outputs for 3-Way, Front, Rear and Subwoofer System Configurations

Product Specifications

•Variable Low Pass Filter: 32-250 Hz

•Variable High Pass Filter: 40-400 Hz

•Signal-to-Noise Ratio: 110 dB

•Crossover Slope: 6dB or 18dB/octave

•Variable Bass Boost: 0 - +12dB @ 45Hz

•Dimensions: 8-1/4"L x 5-1/8"W x 1-7/8"H

Price:

$38 SHIPPED PRIORITY MAIL.

Shipping and Miscellaneous Item Information:

I ship within 24 hours. Payment via Paypal - confirmed name and address only.

Item Pictures:

Click to read more...



[alexn09 10+ year member]

Hey id love to snatch this up today but I have one question. Can this item crossover at higher frequencies? One member, quack head, suggested I use this to crossover at 3.5K between mids and tweets but it doesn't seem to actually be able to do this.

Does the multiplier switch multiply the crossover frequency knob?



[momofx 10+ year member]

Yes it has a mulitplier on a set of channels that takes up to 8Khz, so basically with the 20x multiplier you have a range of 800Hz to 8Khz. To answer your question, yes it multiplies the crossover frequency adjustment by 20 on the adjustment knob.



[alexn09 10+ year member]

Okay thanks and one last question if you don't mind. I have only one full frequency pre out on my headunit. Can I just split it three ways into this crossover and then into my amps ?



[momofx 10+ year member]

Okay thanks and one last question if you don't mind. I have only one full frequency pre out on my headunit. Can I just split it three ways into this crossover and then into my amps ?

Np, Yes you can with this unit. Plug the RCA's into the Front Input and just turn on "Parallel" switch and "Sub Mix" switch //content.invisioncic.com/y282845/emoticons/smile.gif.1ebc41e1811405b213edfc4622c41e27.gif
