Sold FS Lanzar OPTI2000D

[Kryptonitewhite 10+ year member]

barely used, I have a single 2 ohm Fi IB3 18" and the opti loves 1 ohm and .5 ohm, 2 ohm not working for me

$250 plus shipping.

Click to read more...



[bumpintrunk 10+ year member]

bump for a badass .5 ohm stable amp!



[shawn_oneel 10+ year member]

specs???



[Kryptonitewhite 10+ year member]

bump for a badass .5 ohm stable amp!

thanks!



[Kryptonitewhite 10+ year member]

specs???

Car Audio > Amplifiers

MODEL: OPTI2000D

SERIES: OptiDrive

MSRP: $722.19

Optidrive 2000 Watt Half Ohm Stable Mono Block Digital Competition Class Amplifier

SPECS

700 Watts RMS Power @ 4 Ohms

1100 Watts RMS Power @ 2 Ohms

1600 Watts RMS Power @ 1.3 Ohms

2000 Watts Max Power @ 0.5 Ohms

4000 Watts Bridge Max Power @ 2 Ohms

Mono Block Subwoofer Amplifier

0.5 Ohm Stable

MOSFET Power Supply

PWM (Pulse-Width-Modulated) System

Double Sided Epoxy PCB Circuit Board

Gold Plated RCA Inputs

Custom Terminal Block for Speaker Connections

Thermal, Overload Short Protection

Remote Bass Control

Soft Turn On/Off

THD @ 1Watt/4 Ohm: 0.1%

S/N Ratio: 90dB

Frequency Response: 15Hz - 150Hz (+/-3dB)

Damping Factor @ 20Hz/4 Ohms: 400

Low Pass Filter: 50Hz-150Hz, 24dB/Octave

Variable Subsonic Filter: 15Hz-40Hz, 24dB/Octave

Variable Bass Boost: 0 to 18dB

Variable Phase Control: 0 to 180

Input Sensitivity: 200mV ~ 8V

Input Impedance: 10k Ohm

Line Output Impedance: 100 Ohm

Fuse Rating: 30A x 6

Dimensions: 10.08'' (W) x 2.12'' (H) x 19.1'' (L)



[shawn_oneel 10+ year member]

Wonder what it puts out at 1 ohm.......



[Kryptonitewhite 10+ year member]

Wonder what it puts out at 1 ohm.......

I know, I hate how they rated everything... 2000 max at .5??? 1600 at 1.3??? 4000 watts bridge max at 2? RETARDED! So buy it so I can go with Kicker //content.invisioncic.com/y282845/emoticons/biggrin.gif.d71a5d36fcbab170f2364c9f2e3946cb.gif



[DBfan187 5,000+ posts]

http://www.importtuner.com/reviews/parts/0409_impp_amplifier/system.html

TEST RESULTS OUTPUT POWER @ 1%THD, 1KHZ, 14.4VOLTS MONO @ 4OHMS 770 WATTS

MONO @ 2OHMS 1118 WATTS

MONO @ 1OHM 1687 WATTS

MONO @ 0.5OHM 1962 WATTS

OUTPUT POWER @ 1%THD, 1KHZ, 12.5VOLTS

MONO @ 4OHMS 673 WATTS

MONO @ 2OHMS 988 WATTS

MONO @ 1OHM 1406 WATTS

MONO @ 0.5OHM 1635 WATTS

DISTORTION AT RATED POWER, 1KHZ, 14.4VOLTS

0.14% @ IMPEDANCE

INPUT SENSITIVITY 250MV TO 8VOLTS

FREQUENCY RESPONSE ( + 1DB) 15HZ -130KHZ

S/N RATIO (A WEIGHTED, BELOW CLIPPING, MIN GAIN) > 83DB

SLEW RATE 6.5V/MSEC

DAMPING FACTOR @ 100HZ, 4 OHMS 105

IDLE CURRENT 2.1AMPS

MAXIMUM CURRENT CONSUMPTION,

UNCLIPPED 117AMPS @ 1152WATTS

EFFICIENCY AT 1/3RD POWER

LOWEST IMPEDANCE 79%

EFFICIENCY AT FULL POWER, 1%THD,

LOWEST IMPEDANCE 85%

CROSSOVER SLOPE 24DB/OCTAVE

CROSSOVER RANGE, LOWPASS 48HZ - 155HZ

SUBSONIC SLOPE 24DB/OCTAVE SUBSONIC RANGE,

LOWPASS 14HZ - 56HZ

LOW FREQUENCY BOOST +19DB @ 43HZ

DIMENSIONS 19 1/8"L X 10"W X 2.5"H



[Kryptonitewhite 10+ year member]

bump



[Kryptonitewhite 10+ year member]

Sold
