Sold F/S Sundown 3000D, 50.4 and 15" Nightshade

[RetroAudioinc 5,000+ posts]

1. Product:

Sundown Nightshade 15" D2

2. Specs:

If you want a loud subwoofer to use both daily and in the SPL lanes then look no further than the Sundown Audio Nightshade. Many Sundown Audio customers are already using Nightshade woofers to achieve SPL levels in excess of 150 dB on music in their vehicles! *

The Nightshades feature strong paper composite cones with an additional stiffening disc located behind the thick poly dust caps. The tinsel leads are tied down to the spiders so you never have to worry about the leads slapping or popping against the cone and spider at high excursion levels!

The Nightshade woofers are assembled in the USA with only the best high strength adhesives and materials.

* Please use caution as excessive SPL levels such as those achievable with the Nightshade subwoofer can cause permanent hearing damage!

• Dual 2-ohm or Dual 1-ohm Voice Coils Available

• 3" Diameter 8-layer flat-wound Aluminum Wire Voice Coil

• High Temperature Aluminum Voice Coil Former

• 1500-Watts RMS Power Handling

• Over 2 inches peak to peak excursion

• Wide, triple-layer foam surrounds for high excursion

• Extremely strong paper cones w/ stiffening disc

• Thick poly dust caps

• Cast Aluminum 12-spoke basket with cooling vents

• Triple Stacked 1" x 9" magnet slugs for high motor strength

• MSRP - $629 USD


T/S D2 **:

RMS: 1500

Z: 4 ?

Re: 2.92 ?

Fs: 41 Hz

Qms: 9.36

Qes: 0.46

Qts: 0.44

VAS: 11.7 L

BL: 22.8 NA

3. Description/Condition:

Used, I got it on this site from allout13. never had an issue with it, was in 3.5 cube box built by spy, sounds great off my 3000D it will take 3000wrms all day I never had a single issue only did one comp with it.

4. Price: :

$375 shipped

5. Pictures:

Click to read more...



[RetroAudioinc 5,000+ posts]

1. Product:

Sundown 50.4

2. Specs:

The SAX-50.4 was designed as a "little brother" to the SAX-100.4 for those that do not need as much power and/or have limited space to work with. The SAX-50.4 matches very well with the SAZ-1000D as a complete amplification system.

The same crossover features as the SAX-100.4 "C" revision are included.

SPECIFICATIONS:

• 4/3/2 Channel Bridgeable Class-AB Amplifier

• MOSFET PWM Power Supply

• Stable Into 4 Ohms Bridged or 2 Ohms Stereo Load

• 12dB Octave Electronic Crossover Slope

• Variable Subsonic Filter

• Independent 1/2 Channel High Pass Filter Variable with x 10 Range Selectable Switch

• Variable 1/2 Channel Low Pass Filter with HPF/FULL/LPF Selectable Switch

• Independent 3/4 Channel Low Pass Filter Variable with x 10 Range Selectable Switch

• Variable 3/4 Channel High Pass Filter with HPF/FULL/LPF Selectable Switch

• Independent 1/2 and 3/4 Channel Bass Boost Variable Control

• Variable Bass-Boost Frequency Control

• Variable Input Level Control

• Input Sensitivity : 200mV ~ 6V

• Subsonic Filter : 10Hz ~ 500Hz

• Signal Input and Line Out RCA Connectors

• Multi-Way Protection circuitry (Thermal/Over Current/Speaker Short/Speaker DC protection)

• Tested Voltage & THD: 14.4V & Less than 0.05% THD

• Operating Voltage : DC10V~16V Power Input

• Wired Remote Controller

• MSRP $349 USD


Rated power output ----RMS power, 4 ohm stereo

50W x 4CH ----RMS power, 2 ohm stereo

80W x 4CH ----RMS power, 4 ohm bridged

160W x 2CH Signal to Noise Ratio >90dB Low pass frequency crossover

50Hz~500Hz (CH1&2)

50Hz~5KHz (CH3&4) High Pass Crossover

50Hz~5KHz (CH1&2)

50Hz~500Hz (CH3&4) Variable Subsonic Filter 10Hz to 500Hz Bass Boost 0~18dB Variable Bass-Boost Frequency Control 35Hz to 120Hz Frequency Response 10Hz ~ 40KHz (+/-1dB) THD@RMS Watts

3. Description/Condition:

Used in very good condition sounds great have org box as well.

4. Price: :

$180 shipped

5. Pictures:



[RetroAudioinc 5,000+ posts]

1. Product:

Sundown 3000D

2. Specs:

The SAZ-3000D is the big brother to the acclaimed SAZ-1500D amplifier. The SAZ-3000D delivers incredible amounts of power for the most demanding power-users and SPL competitors. This amplifier is not for the weak of heart and was designed to deliver earth shaking power to the biggest and most powerful subwoofers on the market. Sundown Audio only recommends this amplifier for experienced users with an upgraded alternator and additional batteries* due to the enormous power output potential.

​

SPECIFICATIONS:​

• Double Sided Through Hole Epoxy PCB

• Efficiency : 86% @ 4 ohm, at 100Hz

• 24dB/Oct Variable Crossover

• Multi-Way Protection Circuitry

• (Thermal/Over Current/Speaker Short/Speaker DC Protection)

• Variable Subsonic Filter

• Variable Bass Boost

• Variable Low Pass Filter

• Variable Phase Shift

• Zero(0) Gauge Power Supply Connectors

• Tested Voltage & THD : 14.4V & Less than 1% THD

• Operating Voltage : DC 10V~18V

• Digital Class-D Linkable Mono Block Amplifier

• 1 Ohm Stability

• RCA Line Input and Master Output

• 24dB Octave Crossover Slope

• Wired Remote Controller

• MSRP $1549 USD


Rated power output ----RMS power, 2 ohm linkable/dual mono

6000W x 1CH ----RMS power, 1 ohm mono

3000W x 1CH ----RMS power, 2 ohm mono 1600W x 1CH ----RMS power, 4 ohm mono

800W x 1CH Signal to Noise Ratio >90dB Low pass frequency crossover 35Hz~300Hz Subsonic filter 10Hz~60Hz Bass boost @ 45Hz 0~18dB Phase shift control 0~180 degree Frequency response 10Hz~350Hz (+/- 1dB) T.H.D @ 4 ohm

3. Description/Condition:

Used in good conduction, missing one speaker screw nothing that would affect it in any way..

4. Price: :

$550 shipped

5. Pictures:



[RetroAudioinc 5,000+ posts]

1. Product:

1 Sundown Nightshade 12" D1 custom

2. Specs:

Info from Jacob:

They have 3 prototype spiders (little lower Fs than the current models, these are slightly softer), plus double leads, new aluminum pole plugs, and the newest D1 coil with collar vents.

I asked if it would still be ok on 2000wrms and got this:

While this spider is softer at rest it has a progressively increasing stiffness -- so should be fine.

Specs from site should be close:

• Dual 2-ohm or Dual 1-ohm Voice Coils Available

• 3" Diameter 8-layer flat-wound Aluminum Wire Voice Coil

• High Temperature Aluminum Voice Coil Former

• 1500-Watts RMS Power Handling

• Over 2 inches peak to peak excursion

• Wide, triple-layer foam surrounds for high excursion

• Extremely strong paper cones w/ stiffening disc

• Thick poly dust caps

• Cast Aluminum 12-spoke basket with cooling vents

• Triple Stacked 1" x 9" magnet slugs for high motor strength

• MSRP - $629 USD


T/S D1 **:

RMS: 1500

Z: 2 ?

Re: 1.44 ?

Fs: 43 Hz

Qms: 6.83

Qes: 0.43

Qts: 0.40

VAS: 11.7 L

BL: 17.6 NA

3. Description/Condition:

This one was only used by jacob him self I have not used this one still in the org box from jacob. I am using the other 2 in my truck and just did a show with them and they are both on my memphis 4k and sounded great did a 148.7 with them.

4. Price: :

$375 shipped.

5. Pictures:

A few of jacobs photos nothing has changed



[Enellz 10+ year member]

nice GLWS. If I had the money I'll snatch that 3000D off ya



[dbeez 5,000+ posts]

**** I wanted a pair of those 12's jacob built...



[RetroAudioinc 5,000+ posts]

I have one and jacob still has on I think, they are FING LOUD on 4k I did a 148.7 I still have some work to do I hope to get to 150+.. //content.invisioncic.com/y282845/emoticons/smile.gif.1ebc41e1811405b213edfc4622c41e27.gif



[Mattd0344 10+ year member]

any trades???



[kev28 10+ year member]

hey i am looking for a sub or pair



[dbeez 5,000+ posts]

i would have to trade for my pair



[RetroAudioinc 5,000+ posts]

Open to trades or trades + $$$ or just $$$.. Stuff I am looking for is 2 KINETIK HC2400, 2 KINETIK HC1800's, Gray stinger flex 1/0, 4awg, 8awg, blue 4awg and 8awg, also need ends for all of them in blue and black, a IA 40.1 or Sundown 3500D.



[dbeez 5,000+ posts]

I have a 2400.and some monster 1/0



[RetroAudioinc 5,000+ posts]

I have a 2400.and some monster 1/0

Hit me up in a pm with details and pics..



[dbeez 5,000+ posts]

As soon as I get home I will pm me your cell and I can mms them to you...



[RetroAudioinc 5,000+ posts]

My iphone can't get images.. //content.invisioncic.com/y282845/emoticons/frown.gif.a3531fa0534503350665a1e957861287.gif
