1200 Watt Super D-Class Amplifier
1-Channel / Mono Block for Subwoofer Operation
RMS Power Rating: 1200 watts x 1 chan. @ 1 Ohm
RMS Power Rating: 900 watts x 1 chan. @ 2 Ohms
Super D-Class Amplifier Topography
Ultra-Fi MOSFET Outputs
Complementary High-Speed MOSFET Output Devices
MOSFET EXVP (Exponential Vari-Power Supply)
SPC Twin Turbo Torroids with Sympatico Coil Design
Power and Protection LEDs>/li>
21st Anniversary Edition Heat-Sink Design
Illuminated Hifonics Logo and Maxxsonics M
Gold RCA Inputs
Balanced Line Inputs
Soft Start
4-Way Protection Circuitry: DC, Speaker Short, Thermal, Overload
Fully Adjustable Accu-Cross Crossover Includes:
Low-Pass Filter: 35 - 250 Hz
Subsonic Filter: 15 - 35 Hz
Phase Adjustment: 0° - 180°
Variable Bass Equalization: 0 - 18 dB @ 45 Hz
Input Level Adjustment: 0.2V - 9V
Wired Bass Remote Included
RCA Outputs: 1 Pair
Gold 4-Gague Power Connectors
Dimensions: 11.41" L x 10.39" W x 2.63" H
Specifications:
Number of Channels 1 - Mono
RMS Power (4 ohms) 450 watts x 1 chan.
RMS Power (2 ohms) 900 watts x 1 chan.
RMS Power (1 ohm) 1200 watts x 1 chan.
Bridged RMS Power Not Bridgeable
Peak Power Output 2400 watts approx.
Min. Impedance Unbridged 1 Ohm
Min. Impedance Bridged Not Bridgeable
THD @ Rated RMS Power 0.08%
Speaker Level Inputs No
Amp Preamp Outputs Yes - 1 Pair
Built-in Crossover LPF(35 - 250 Hz), Subsonic(15 - 35 Hz)
Bass Boost 0 - 18 dB @ 45 Hz
Signal-to-Noise Ratio 95 dB
Fan Cooled No
Fuse Rating 80A
