Hello, quick question,
Im getting ready to purchase an ESX Q120.4.
As per specs, Im gonna be running channels 1+2 to the front mids/highs which is 120x2 @4ohm stereo and bridging channels 3+4, 360x1 for my single 4 ohm Kicker s10c solobaric sub.
I was told these amps are underrated, so does that mean they will actually do more power? How much more ?
My kicker sub can handle 350watts rms in a 0.66 cu ft sealed box, and 450watts rms in a 0.60 cu ft box.
Should I build the smaller or bigger sub box ?
Heres the specs of my sub.
http://www.kicker.com/sites/default/files/Solo-Baric%20-%20C-%20Series%20Subwoofers.pdf
ESX Quantum Q120.4 SPECS:
http://ampguts.realmofexcursion.com/ESX_Quantum_Q120.4/
Output Power at 12V:
4 x 120W @ 4 ohms
4 x 180W @ 2 ohms
2 x 240W @ 8 ohms bridged
2 x 360W @ 4 ohms bridged
2 x 150W @ 4 ohms bridged "TRUE MONO"
2 x 240W @ 2 ohms bridged "TRUE MONO"
2 x 360W @ 1 ohm bridged "TRUE MONO"
2 x 250W @ 4 ohms bridged "TRUE MONO / HIGH VOLTAGE"
2 x 400W @ 2 ohms bridged "TRUE MONO / HIGH VOLTAGE"
1 x 300W @ 8 ohms "MONOBLOCK"
1 x 500W @ 4 ohms "MONOBLOCK"
1 x 720W @ 2 ohms "MONOBLOCK"
1 x 500W @ 8 ohms "MONOBLOCK / HIGH VOLTAGE"
1 x 800W @ 4 ohms "MONOBLOCK / HIGH VOLTAGE"
Made by Zed Audio
Im getting ready to purchase an ESX Q120.4.
As per specs, Im gonna be running channels 1+2 to the front mids/highs which is 120x2 @4ohm stereo and bridging channels 3+4, 360x1 for my single 4 ohm Kicker s10c solobaric sub.
I was told these amps are underrated, so does that mean they will actually do more power? How much more ?
My kicker sub can handle 350watts rms in a 0.66 cu ft sealed box, and 450watts rms in a 0.60 cu ft box.
Should I build the smaller or bigger sub box ?
Heres the specs of my sub.
http://www.kicker.com/sites/default/files/Solo-Baric%20-%20C-%20Series%20Subwoofers.pdf
ESX Quantum Q120.4 SPECS:
http://ampguts.realmofexcursion.com/ESX_Quantum_Q120.4/
Output Power at 12V:
4 x 120W @ 4 ohms
4 x 180W @ 2 ohms
2 x 240W @ 8 ohms bridged
2 x 360W @ 4 ohms bridged
2 x 150W @ 4 ohms bridged "TRUE MONO"
2 x 240W @ 2 ohms bridged "TRUE MONO"
2 x 360W @ 1 ohm bridged "TRUE MONO"
2 x 250W @ 4 ohms bridged "TRUE MONO / HIGH VOLTAGE"
2 x 400W @ 2 ohms bridged "TRUE MONO / HIGH VOLTAGE"
1 x 300W @ 8 ohms "MONOBLOCK"
1 x 500W @ 4 ohms "MONOBLOCK"
1 x 720W @ 2 ohms "MONOBLOCK"
1 x 500W @ 8 ohms "MONOBLOCK / HIGH VOLTAGE"
1 x 800W @ 4 ohms "MONOBLOCK / HIGH VOLTAGE"
Made by Zed Audio
