1. Product:
DC AUDIO LVL4 10" WITH LVL5 UPGRADES
2. Specs:
3. Description/Condition:
Motor is used, everything else brand new. Works great, I hooked it up on my test bench and let it play for about 3 hours to losen it up a bit as it was very very very stiff.. Motor has a few little scratches on the bottom from being moved around but nothing major at all..
4. Price: :
$300 shipped.
5. Pictures:
DC AUDIO LVL4 10" WITH LVL5 UPGRADES
2. Specs:
REMEMBER THIS IS ALL UPGRADED TO DC LVL5 SOFTPARTS SO IT WILL TAKE A LOT MORE POWER!
Level 4
This sub was designed to make people angry.
With sick amounts of output, it’s hard to beat!
The Level 4 sub is a large double stacked motor weighing in at almost 30LBS each, wrapped in a magnet boot with a chrome top plate and T yoke yielding 23.5mm of X-Max
You also get with the upgraded progressive spiders, cone, surround, 3" coil, cast basket, push terminals and upgraded lead wire.
The Level 4 is rated at 1000w RMS and 2000w peak. Designed for ported enclosures and is a great choice for high-powered daily systems and competitors.
Key Features
• Extremely rigid non-pressed paper cone assembly
• Multilayered polymer foam surround
• Polypropylene dust cover with embossed DC logo
• 8”OD semi cup progressive roll spider
• Extra heavy duty interweaved tinsel lead wire
• Cast aluminum black frame
• FEA analyzed and optimized motor assembly – Fully CNC machined
• Rubber mounting gasket
• Chrome spring loaded push terminals
• Dual 2 ohm 3” Hi-temp Aluminum voice coil wound on black anodized voice coil former
• Rubber magnet cover
Level 4
This sub was designed to make people angry.
With sick amounts of output, it’s hard to beat!
The Level 4 sub is a large double stacked motor weighing in at almost 30LBS each, wrapped in a magnet boot with a chrome top plate and T yoke yielding 23.5mm of X-Max
You also get with the upgraded progressive spiders, cone, surround, 3" coil, cast basket, push terminals and upgraded lead wire.
The Level 4 is rated at 1000w RMS and 2000w peak. Designed for ported enclosures and is a great choice for high-powered daily systems and competitors.
Key Features
• Extremely rigid non-pressed paper cone assembly
• Multilayered polymer foam surround
• Polypropylene dust cover with embossed DC logo
• 8”OD semi cup progressive roll spider
• Extra heavy duty interweaved tinsel lead wire
• Cast aluminum black frame
• FEA analyzed and optimized motor assembly – Fully CNC machined
• Rubber mounting gasket
• Chrome spring loaded push terminals
• Dual 2 ohm 3” Hi-temp Aluminum voice coil wound on black anodized voice coil former
• Rubber magnet cover
10"
Mounting Depth
6.25"
Mounting Hole Diameter
9.25"
Motor Width
7.75"
Weight
31.5lbs
VC Diameter
3"
Magnet Weight
28.5lbs
Power Handling RMS/Peak
1000/2000
Impedance
D 2ohm
Sd
314.00 cm²
Vas
27.40 L
Cms
1.99e-04 m/N
Mms
115.70 g
Fs
33.2 Hz
Bl
16.15
Re
3.60 ohm
Le
4.02 mH
Qms
5.15
Qes
0.43
Qts
0.40
Xmax
23.5 mm
Sensitivity
85.50 dB
Suggested Sealed
N/A
Suggested Ported
1³ ft
Suggested SPL Ported
1.25³ ft
3. Description/Condition:
Motor is used, everything else brand new. Works great, I hooked it up on my test bench and let it play for about 3 hours to losen it up a bit as it was very very very stiff.. Motor has a few little scratches on the bottom from being moved around but nothing major at all..
4. Price: :
$300 shipped.
5. Pictures:
