Item(s) for Sale: 1 Custom Built TC-7+ 12 D4
Item(s) Description/Condition: Cosmetics:9/10 Because the basket,terminals, and motor are used but the cone,dustcap,spiders, and coil are new with only 30 minutes of total playtime. Performance: 10/10 The sub is in absolute perfect working order. It uses dual 8.75" TC Sounds Linear Roll Spiders, A custom made 5/8" spider spacer, a 3 spoke basket that I cannot identify but it is extremely strong, a TC-7+ motor (the plus has the copper shorting ring in the gap to lower inductance), A TC Sounds TC-2000 D4 (Reads 3.4 per side) Roundwire Copper Coil,A sundown large roll rubber surround, a sundown heavy duty pulp cone, sundown 7" plastic dustcap, and a eclipse motor cover. The sub is rated for 1000 watts rms daily I would not recommend putting anymore than this because at 1000 watts rms in a sealed box it reaches max excursion with ease but thermally it could handle 1000 watts rms with plenty of ease. The sub mounting depth is 8.75" (which includes pole vent space.) the sub is 13" in overall diameter with a cutout of 11.75". Here are the T/s Parameters.
Re - 7.575
Fs - 26.24 hz
Qts - 1.02
Qes - 1.4
Qms - 3.756
Le - 1.562 mH
Mms - 254.7 g
Vas - 42.42 L
Sensitivity - 79.56 @ 1w/1m
Xmax-28 mm One-way
Bl - 16.1 Tm
Price: PRICE DROP $150 shipped!. I will use USPS. If you want another shipping company please tell me and I will get you a quote.
Recommended box sizes: Sealed 1.5-2 cubes stuffed with 2 pounds of polyfill Ported 2.25-3.25 cubic ft tuned anywhere from 28-32 hz.
Shipping and Miscellaneous Item Information: I will use USPS. If you want another shipping company please tell me and I will get you a quote.
Item Pictures:
(List pictures in this section, 1st picture should be your username/date if you have less than 10 positive feedbacks with the i-Trader system or less than 10 references that you have sold to in the past. (These must be listed in your signature, or a link provided to a feedback thread listing these references)).
Item(s) Description/Condition: Cosmetics:9/10 Because the basket,terminals, and motor are used but the cone,dustcap,spiders, and coil are new with only 30 minutes of total playtime. Performance: 10/10 The sub is in absolute perfect working order. It uses dual 8.75" TC Sounds Linear Roll Spiders, A custom made 5/8" spider spacer, a 3 spoke basket that I cannot identify but it is extremely strong, a TC-7+ motor (the plus has the copper shorting ring in the gap to lower inductance), A TC Sounds TC-2000 D4 (Reads 3.4 per side) Roundwire Copper Coil,A sundown large roll rubber surround, a sundown heavy duty pulp cone, sundown 7" plastic dustcap, and a eclipse motor cover. The sub is rated for 1000 watts rms daily I would not recommend putting anymore than this because at 1000 watts rms in a sealed box it reaches max excursion with ease but thermally it could handle 1000 watts rms with plenty of ease. The sub mounting depth is 8.75" (which includes pole vent space.) the sub is 13" in overall diameter with a cutout of 11.75". Here are the T/s Parameters.
Re - 7.575
Fs - 26.24 hz
Qts - 1.02
Qes - 1.4
Qms - 3.756
Le - 1.562 mH
Mms - 254.7 g
Vas - 42.42 L
Sensitivity - 79.56 @ 1w/1m
Xmax-28 mm One-way
Bl - 16.1 Tm
Price: PRICE DROP $150 shipped!. I will use USPS. If you want another shipping company please tell me and I will get you a quote.
Recommended box sizes: Sealed 1.5-2 cubes stuffed with 2 pounds of polyfill Ported 2.25-3.25 cubic ft tuned anywhere from 28-32 hz.
Shipping and Miscellaneous Item Information: I will use USPS. If you want another shipping company please tell me and I will get you a quote.
Item Pictures:
(List pictures in this section, 1st picture should be your username/date if you have less than 10 positive feedbacks with the i-Trader system or less than 10 references that you have sold to in the past. (These must be listed in your signature, or a link provided to a feedback thread listing these references)).
