Custom box, made specially for JL 10W7's

[DanCap 10+ year member]

Just got my box in today!

It is hand crafted from Av Priority Custom box builders out of New York!

This is a custom box designed only for 2- JL 10W7's, I was impressed with the flawless design!

Just look a the pics, can't wait to get this system bumping!

Click to read more...



[THUNDERBIRD 10+ year member]

sweet looks awesome, what are the specs on it.



[60ndown 10+ year member]

are they the new 'transparent series' from jl?

nice box, i bet it was $350 +



[helotaxi 5,000+ posts]

Looks like excellent build quality. What's with the skinny *** ports though?



[k12ug 10+ year member]

$?



[James Bang 5,000+ posts]

looks like a good build, but i'm not digging the white port trim.



[DanCap 10+ year member]

It was 245 shipped! Its a guy that builds boxes specially for Jl subs located in NY.

Great quality! my 10w7's should be in next week, i will put up a sound clip when its installed, should bump!

Those ports look skinny but there really not at all, and if i had a picture that shows the back of the inside of the box the ports go through like a zig zag, something different, but i like it!



[Max_Power 10+ year member]

wow, That box is robust. I'm loving the support inside it. whats the specs on it?



[neonrt 10+ year member]

Looks like excellent build quality. What's with the skinny *** ports though?

x2 on the ports.//content.invisioncic.com/y282845/emoticons/confused.gif.e820e0216602db4765798ac39d28caa9.gif



[mannyb18b]

looks like there 1 inch wide? how tall? how much port area



[ssj2xxgotenxx 10+ year member]

I gotta learn how to make bracing like that.



[mlstrass 5,000+ posts]

Also looks like the port walls aren't touching the bottom of the box.

How would you calculate displacement for those braces? That's the reason I've never tried them....



[SAG3 5,000+ posts]

Braces are sweet.



[DanCap 10+ year member]

It features ported design construction using 3/4" MDF for the main enclosure along with the internal bracing and 1" MDF front baffle's for mounting the subs. The gross internal volume per side is 1.58 cu.ft.

The use of the internal bracing strengthens the enclosure substantially for an enclosure that is truly rock solid. Each brace is fitted into dado's on all four sides to further add strength.

This is a real beast weighing in at 68 lbs. Box dimensions are as follows:

35 3/4" wide, 16" high, 16" deep.



[packerfan 10+ year member]

Hmmm Overspray from the port wall not bein sealed to the bottom of the box.....nice quality i guess?
