can anyone do 3d draw of this box?

[chunky cumz 10+ year member]

can anyone do 3d draw of this box? or a cut sheet?

ok the deminsions are like this. This is an HHR. back seats are at 60/40 setup if you were to do and angled box it would be like this

width is 39" (side to side of car

height 16" (height of box)

length 32"(front to back of car)

The back angle of the box would be a 67 degree angle with the wood being the length of 18"

//content.invisioncic.com/y282845/emoticons/frown.gif.a3531fa0534503350665a1e957861287.gif

Click to read more...



[ls2poweredgoat 5,000+ posts]

Help a brotha out!



[edzy 10+ year member]

here you go bro.



[chunky cumz 10+ year member]

you are da shyt. see my sig



[edzy 10+ year member]

lol, nice.

well you didnt say you wanted a cad drawing.

Why dont you dl bb6 or something?

Heres a link to a bunch of free desiners.

http://diyaudiocorner.tripod.com/software.htm

and RE has a basic one too.



[chunky cumz 10+ year member]

lol, nice.
well you didnt say you wanted a cad drawing.

Why dont you dl bb6 or something?

Heres a link to a bunch of free desiners.

http://diyaudiocorner.tripod.com/software.htm

and RE has a basic one too.

i just watched your video bro. you are fuking crazy! i bet you cant hear shyt! lol



[edzy 10+ year member]

what?



[chunky cumz 10+ year member]

what?

lol cant hear me huh



[edzy 10+ year member]

play with this one.

http://www.reaudio.com/speaker_box/LPort_Box_Calc.html



[Atimm693 10+ year member]

Google Sketchup works as well, but takes some time to get up to speed with....



[fbi90909 5,000+ posts]

you're missing a measurement. the measurements you gave are pretty much a standard box. the 4 measurement needed ss for the depth of either the top or bottom to acheive the angle..

basically, which is 32" long/deep, the bottom or the top? how long with the stop be?



[chunky cumz 10+ year member]

you're missing a measurement. the measurements you gave are pretty much a standard box. the 4 measurement needed ss for the depth of either the top or bottom to acheive the angle..basically, which is 32" long/deep, the bottom or the top? how long with the stop be?

you right bro, i know the angle is 67 degrees so does anyone know of a calucator that would give us that top length?



[IDSkoT 5,000+ posts]

you right bro, i know the angle is 67 degrees so does anyone know of a calucator that would give us that top length?

You can use the Tangent formula...?



[chunky cumz 10+ year member]

geometry was several years ago for me. lol havnt used it since.



[IDSkoT 5,000+ posts]

There you go, buddy!

Now I demand a permanent spot in your sig... //content.invisioncic.com/y282845/emoticons/fyi.gif.9f1f679348da7204ce960cfc74bca8e0.gif
