Sold Apex jr Super 8's in 1/2 Wave T-Line with Flared Kerf port

[jdubbau 10+ year member]

Apex Jr. Super 8’s (x2) in ½ wave T-Line with Kerfed Port

Specs:

FS=47.75Hz

Qms=7.334

Qes=.552

Qts=0.514

Vas=0.376 cu. ft.

Re=2.653 ohms

Le=0.157mH

Spl=85.22 @ 1w/1m

SUB Box is designed specifically for these Apex Jr. Super 8’s in a ½ Wave Transmission Line enclosure with a kerfed port. YES ½ Wave.

Sounds spectacular off of only 80 watts in my home and in my vehicle just amazing output and on a broad band of bass frequencies. Box is larger as it is a ½ Wave T Line as it is 31” L x 18.5” x 21”

Built with ¾ Mdf, black fleck Painted Flared Kerf port, 45’s in corners, and will be putting better carpet on the box before it leaves out.

Description/Condition:

10/10 Mech and 9.5/10 Cosmetic only use almost new condition.

Price: :

$225 Plus shipping OBO

Pictures:

Click to read more...



[drtjmpr909 10+ year member]

Its going in an 06 suzuki forenza...will get the dims in a bit. What is the max power these can take on music? All I have currently is a Powerbass Extreme 1500. Does max at 1 ohm



[drtjmpr909 10+ year member]

33lx15dx15t



[jdubbau 10+ year member]

I can make it work like it is supposed to with in those dimensions.

33lx15dx15t

Your amp would be fine as you can do 1.5ohm at around 750w+ as these are ok with 200-250w a piece daily but some have done 300w a piece.



[jdubbau 10+ year member]

Up still here



[AudioFreak 10+ year member]

Trades?



[jdubbau 10+ year member]

Trades?

Yes open to trades what do you have in mind??



[jdubbau 10+ year member]

$165 shipped con us

12/24 deal



[jdubbau 10+ year member]

$165



[jdubbau 10+ year member]

Santa Bump



[jdubbau 10+ year member]

Up



[jdubbau 10+ year member]

$165 shipped con us



[jdubbau 10+ year member]

UP still here



[supermaxx123 10+ year member]

I'm a little curious as to why there is foam in the corners? nice build!



[jdubbau 10+ year member]

I'm a little curious as to why there is foam in the corners? nice build!

I always try to fill the space behind my 45's as some may think it is pointless or does not help at all but I just figured it cant hurt as its got to be better than dead space and could make the box slightly sturdier. I also will typically fiberglass the inside of the kerfed port after using some mdf paste, bondo over it and sand smooth, and bondo over 45's to smooth and round off as best I can. Kind of overbuilt to some but I like doing it. I guess I am about to build a 1/4 wave box with a little more time put into it as I assume my test box here is not a hit at all as it is on the large size for some 8's but it is also a 1/2 wave box.



[jdubbau 10+ year member]

Ok I am about to start a build on a 1/4 wave for these Apex super jr 8's that will be similar to the box below I did for the Sa8 below. The box will be more like 31"L x 10"d x 16.5"h

No longer selling the 1/2 wave but feel free to jump on a custom T-Line box for your vehicle with these Apex 8's as it should be right at $175 shipped!! Con Us only
