anyone need 3d sketches?

[trevor87 5,000+ posts]

i thought they were free i already designed the box just need a cutsheet or sketch like u made icpurpleppl



[baseballer1100 5,000+ posts]

**** i knew i was pushing it. lol



[PhatTonyDeMarco 5,000+ posts]

42" wide x 22" deep x 20" high

18" driver centered firing up, double baffle with the second baffle being a flush mount rather than the sub sitting on top of it

port is 40.5" wide x 3" tall, running along the bottom of the front of the enclosure

Let's see what ya got //content.invisioncic.com/y282845/emoticons/smile.gif.1ebc41e1811405b213edfc4622c41e27.gif



[mobeious 10+ year member]

baseballer



[baseballer1100 5,000+ posts]

woot. thanks dude.



[saywhat? 5,000+ posts]

nah.



[mobeious 10+ year member]

phat tony



[baseballer1100 5,000+ posts]

Your the man.



[trevor87 5,000+ posts]

i gave you the same thing everyone else gave you, my dimensions, and i get skipped on the free sketch? u could have done the sketch for me and not did the cutsheet, if that was the only free part, just confused here



[mobeious 10+ year member]

trevor



[FiFdYnUtZ 10+ year member]

i need a sketch of a box for a 12" FI Q... 2.5 cubes with 36 sqin of port, tuned to 34hz. and it needs to fit in a grand prix trunk...dimensions would kick *** too! thanks!



[cooper1513 10+ year member]

4.5 cubic ft tuned to 30htz, 15, sub firing up port on bottom firing to back

http://www.alphasonik.com/600%20Series%20Parameters.pdf



[trevor87 5,000+ posts]

thanks sir



[dvrmstrng 5,000+ posts]

i could really use one as well...sealed with an 18" cutout...dimensions are 40" wide, 19.5" tall and 12" deep....thanks man!!



[nismos14 5,000+ posts]

33 (w) x 9 (d) x 13 (h) w/ 30 hz tune
