amp name it, just picked it up dont know what it is LOL

[mclerico83 5,000+ posts]

has nice 4 guage wires and some hefty 10 guage speaker wires out of it

Click to read more...



[ThaWaxShop 10+ year member]

Written right on the board lol 50hca



[DonH 5,000+ posts]

nice OS amp. it work?



[mclerico83 5,000+ posts]

i know i looked at the guts of some 50hca's dont match up



[mclerico83 5,000+ posts]

yes it works



[mclerico83 5,000+ posts]

US Amps 50HCA - Amp Guts



[brynm 10+ year member]

Nothing on the sides at all?

You could always email the pics to tech@usamps.com and ask them.



[brynm 10+ year member]

i know i looked at the guts of some 50hca's dont match up

It could just be a different version.



[akheathen Premium Member]

....... and, that looks like 8awg power/ground, not 4....



[bugflipper 10+ year member]

It is a 50 hca as stated above. They came in different colors and sizes through the years. I remember red, blue and black for the one you have pictured. This one would have been from the early 90's. Some of the blue ones even came with american flag boards. They were a "cheater" amp copied from an orion hcca series. Any info you find on an orion hcca 250 is accurate for this one.

50x2 @4ohms

100x2@2

200x2@1

400X2@.5

200x1@4

400x1@2

800x1@1

snr 100db

thd .006

fr 50-50k

Orion sued them in the late 90s and they had to change the guts. The power dropped quite a bit then. I think the lower power one was the 50hc after the lawsuit, to many years ago though, not sure. It had a different heat sink than this one though. And did not have the orion style guts. If you soldered in a heavier power and ground and upgraded you electrical to feed them well, they would go 1600x1@.5 ohms or 800x2@.25. Almost all of my sub amps are os orion hcca. 15-20 years later they are still going strong. What can be said about them can be said about this line up of the os us amps.



[akheathen Premium Member]

hmm.... i haven't seen t03 form transistors support more than 150wrms power dissipation with the best of cooling....... circuitry suggests 1200w x1... the one on ampguts only suggests 900w x1 with to-220s
