I was thinking the same thing. All those clips look nice down each side but alot of them are not holding transistors down. Kinda looks like more effort put in the crossover than the amp. Clean work though.



[i3abyjay25 10+ year member]

Orion XTR Pro 2400



[3.5Max6spd 10+ year member]

Arc audio XXK4000.....



[UndercoverPunk 5,000+ posts]

Arc audio XXK4000.....

Is that the one that's supposedly full range?



[s40pé]

Precision Power AX 400(1994)

specs 4x50w at 4ohm

4x100 at 2ohm



[s40pé]

next of my collection is the Precision Power PRO ART 25

specs 2x25w at 4ohm

2x50w at 2ohm

2x100w at 1ohm



[s40pé]

sorry for the big ax400 i will do it again



[s40pé]

here are my 2 beauties together with an spacer link from ppi.



[3.5Max6spd 10+ year member]

Is that the one that's supposedly full range?

class a/b yes...although there may not be but a few of these around...the upcoming 4000SE is a whole new board/design....



[Pop da Hatch 10+ year member]

http://www.realmofexcursion.com - has the new amp guts page - most ive seen anywhere lately - might have already been said - but I dont wanna read the whole thread!



[toaster 10+ year member]

oh those ppis are lovely....



[s40pé]

thanks man

here my sub amp Precision Power DCX500.2 (2x125w at 4ohm)



[maxxguy1 10+ year member]

heres the autoteck mm 4000.1
