Item(s) for Sale:
1) Alpine MRP-M2000 2000x1 @ 2 ohm
2) Alpine MRP-F300 50x4 @ 4 ohm
Item(s) Description/Condition:
Both in great condition, used and work great. As of right now do not have the end caps. But may locate them, will update if so.
1) MRP-M2000 SPECIFICATIONS ( http://http://www.alpine-usa.com/product/view/mrp-m2000/default )
CEA-2006 Power Ratings
CEA-2006 Power Rating: (2 I? @14.4V Ƈ% THD+N), S/N: 75dBA, ref:1W into 4 I?) 2000Wx1
RMS Power Ratings
Per channel into 4 Ohms: (@ 14.4V Ƈ%THD+N, 20Hz - 200Hz) 1500Wx1
Per channel into 2 Ohms: (@ 14.4V Ƈ%THD+N, 20Hz - 200Hz) 2000Wx1
Sound Tuning
Crossover: 50-200Hz
EQ (Equalizer): Center Frequency Adjustment 30-80Hz, Gain 0-12dB
Subsonic Filter: 0, 15, 30Hz
Dimensions
Foot Print (WxHxD) mm: 514mm x 242mm x 60mm
Foot Print (WxHxD) in: 20-1/4'' x 9-7/32'' x 2-23/64''
Heat Sink (WxHxD) mm: 451mm x 242mm x 60mm
Heat Sink (WxHxD) in: 17-3/4'' x 9-7/32'' x 2-23/64''
General
Power Requirements: 14.4V DC (11V to 16V)
Frequency Response: 20Hz - 200Hz
Speaker Impedance: 2 - 4 I?
Signal to Noise: 75dBA
FEATURES
Install
Terminal Layout: Two Sided
Screw Mount / Wire Cover: Integrated Wire and Mounting Screw Terminals
General
Amplifier Type: Class-D
Channel Design: Mono Amplifier
Thermal Control: Thermal Management Control
Power Supply: DC-DC PWM Power Supply
Power Supply Design: MOSFET
Board Circuitry: Globally Modulated Design
Current Protection: Automatic Over-Current Protection Circuitry
Power Indicator: Top Mounted Blue LED Power Indicator
RCA Output: Gold Plated RCA Input Connector
Speaker-Level Inputs: Speaker Level Inputs
Crossover: Adjustable Low-Pass
Connector Plating: Gold Plated Input, Output, Power and Speaker Terminals
Board Design: Dual Sided Glass Epoxy PC Board
Gain Control: 2-Position Gain Setting
2) MRP-F300 SPECIFICATIONS ( http://http://www.alpine-usa.com/product/view/mrp-f300/default )
CEA-2006 Power Ratings
CEA-2006 Power Rating: (4 I? @14.4V Ƈ% THD+N, S/N: 80dBA, ref:1W into 4 I?) 50W x 4
RMS Power Ratings
Per channel into 4 Ohms: (@ 14.4V Ƈ%THD+N, 20Hz - 20kHz) 50W x 4
Per channel into 2 Ohms: (@ 14.4V Ƈ%THD+N, 20Hz - 20kHz) 75W x 4
Bridged 4 Ohms: (@ 14.4V Ƈ%THD+N, 20Hz - 20kHz) 150W x 2
Sound Tuning
Crossover: 50Hz-400Hz, -12dB/oct. (Low-Pass/High-Pass)
EQ (Equalizer): Bass EQ (Fixed Frequency): 50Hz +12dB
Subsonic Filter: 15Hz (Fixed), -18dB/oct.
Dimensions
Foot Print (WxHxD) mm: 270mm x 60mm x 242mm
Foot Print (WxHxD) in: 10-15/16'' x 2-23/64'' x 9-27/32''
Heat Sink (WxHxD) mm: 210mm x 60mm x 242mm
Heat Sink (WxHxD) in: 8-17/64'' x 2-23/64'' x 9-33/64''
General
Power Requirements: 14.4V DC (11V to 16V)
Input Sensitivity: 0.2 - 4.0V
Frequency Response: 20 -20kHz (0, -1dB)
Speaker Impedance: 4 or 2 I?
Signal to Noise: 100dBA
FEATURES
Install
Terminal Layout: Two-Sided
Screw Mount / Wire Cover: Integrated Wire and Mounting Screw Terminals
General
Amplifier Type: Class-A/B
Channel Design: 4/3/2 Channel
Thermal Control: Thermal Management Control
Power Supply: DC-DC PWM Power Supply
Power Supply Design: MOSFET Power
Board Circuitry: STAR Circuitry
Current Protection: Over-Current, Over-Voltage and Thermal Protection
Power Indicator: Top Mounted Blue LED Power Indicator
RCA Output: Gold Plated RCA Input Connectors
Speaker-Level Inputs: Speaker Level Inputs
Crossover: Adjustable Low-Pass/High-Pass
Connector Plating: Gold Plated Input, Output, Power and Speaker Terminals
Pre-Amp Stage: Discrete
Final Outputs: Non-Fading Pre-Amp Output
Board Design: Dual Sided Glass Epoxy PC Board
Gain Control: Continuously Adjustable Gain Control
Price:
1) Alpine MRP-M2000 350+ Shipping
2) Alpine MRP-F300 100+ Shipping
Shipping and Miscellaneous Item Information:
Buyer pays shipping.
Item Pictures:
(List pictures in this section, 1st picture should be your username/date if you have less than 10 positive feedbacks with the i-Trader system or less than 10 references that you have sold to in the past. (These must be listed in your signature, or a link provided to a feedback thread listing these references)).
See more. Alpine amps pictures by HIPGC - Photobucket
See more. f300 pictures by HIPGC - Photobucket
