6.5" prototype mids

Status
Not open for further replies.

psychoacoustics
10+ year member

hammer and the evil one
3,468
0
Buffalo NY
Item(s) for Sale:

these are a prototype i picked up they look very nice!!!

i can pull some t/s specs if you need them not a problen

it appears to be a 1" voice coil copper wire poly cone and dust cap rubber surround cloth spider

very high build quality for sure check the close up

Item(s) Description/Condition:

6.5" mid-range 10 spoke basket looks very similar to a dc with the 12 spoke basket actually

Price: 80$ shipped for the pair

i can add a set of american bass tweeters and crossovers in for another 40

Shipping and Miscellaneous Item Information:

shipped and insured to the lower 48

Item Pictures:









(List pictures in this section, 1st picture should be your username/date if you have less than 10 positive feedbacks with the i-Trader system or less than 10 references that you have sold to in the past. (These must be listed in your signature, or a link provided to a feedback thread listing these references)).


mounting depth is in the picture look closely

i canget t/s stuff soon im stuck at toyota dealership with my brand new taco and the tpms lights on for months ! very frustrated toyota is not my friend today


ts specs :

Re = 3.4235 ohms

Fs = 108.5048 Hz

Zmax = 11.4865 ohms

Qes = 1.4255

Qms = 3.3574

Qts = 1.0007

Le = 0.3437 mH (at 1 kHz)

Diam = 406.4000 mm ( 16.0000 in )

Sd =129717.1116 mm^2(201.0619 in^2)

Vas = 346.1002 L ( 12.2224 ft^3)

BL = 4.9324 N/A

Mms = 14.8593 g

Cms = 144.7914 uM/N

Kms = 6906.4878 N/M

Rms = 3.0174 R mechanical

Efficiency = 29.1425 %

Sensitivity= 106.6633 dB @1W/1m

Sensitivity= 110.3495 dB @2.83Vrms/1m

trades ehhh ill entertain but i doubt it list it here or pm me whatever

never hooked them up

selling cuz i have tooooooooo much stuff
