15" TC sounds 3hp neo

[resko1 10+ year member]

Item(s) for Sale:

15" TC Sounds 3hp neo

Item(s) Description/Condition:

3Hp neo motor non-linear

15" TI basket

Quad 1 ohm 8 layer coil wired to d2

2- medium spaced TC spiders dual sewn leads

15" pro5200/ aura 1508 cone (proto) Dont let the cone fool you. Will reach 2.5"-3" peak to peak.

FS-34.32hz

QES-0.443

QMS-7.863

QTS-0.419

VAS-56.15L

MMS-269g

Bl-21.04tm

Le-2.13mH

Re-3.381ohms

xmax- 28mm

xlim-34mm

Pe-2000w

SPL-92.87db

I have a folded horn design for this driver that requires about 7-8cu total box but shows a 148-150db level, 1 meter from the horn mouth on 1500w rms. I have included one pic of the hornresp parameters and one of the hornresp 0.5pi loading response. Should be a 2db cabin gain in car and have a response that extends down about 8 more hz.

For those that dont know what hornresp is its a horn modeling program created by david mcbean and EXCELLENT software, but tricky to use.

New/rebuilt sub. Tested for functionality and TS parameters pulled. Box required is too big for my 300zx.

Price:

300 plus shipping.

Only trades i would consider is for a double din headunit.

Shipping and Miscellaneous Item Information:

Shipping is from 53081. Box will be 18x18x16 and 35#

Item Pictures:

(List pictures in this section, 1st picture should be your username/date if you have less than 10 positive feedbacks with the i-Trader system or less than 10 references that you have sold to in the past. (These must be listed in your signature, or a link provided to a feedback thread listing these references)).

Click to read more...



[hispls 5,000+ posts]

Great price! Worth most of that just for the motor and frame.

Have you ever done a horn build? Any pics? Free bump anyway for a cool sub. GLWS



[resko1 10+ year member]

Thanks.

Actually ive done a few. Im still yet to see a true horn build in a car. Ive seen some rear loaded designs pwk did but theyre more along the lines of ported/tapered enclosures. I did 2 bins a few months ago for a dj buddy. Used 18" b&w's and it was absurd. He was running the pair off 2000w crown and 6 jbl dual 15's for the mains and actually had to dial the level down to get his mix.

Ive never tried it in car though. I was going to use this sub in a 40hz front loaded horn for db drag street stock but i cant fit a 7-8cu box in my nissan 300zx.



[resko1 10+ year member]

Bump it up guys
