Zeuslicious 5,000+ posts
<< 28hz feels good
1. Product:
15" Fi SP4 15s Dual 1 ohm
2. Specs:
Dual 1
Extra heavy aluminum basket
Wrap around gasket
Kraft pulp fiber reinforced cone
Single layer wide foam surround
Push terminals
144 tinsel count leads
FEA optimized motor
High Flux density design
4” diameter 4 layer coil (Flatwind standard)
Double stack magnets
Five progressive 10" spiders
Optional Heli-cool systerm
Machined in house at Fi
And many other custom options SP415
DUAL 1 | DUAL 2 Fs: 27.6 Hz | 27.9 Hz Re: 0.65 Ohms/coil | 1.27 Ohms/coil Qms: 6.56 | 6.45 Qes: .52 | .52 Qts: .48 | .48 Mms: 434g | 424g Cms: 0.77mm/N | 0.77mm/N Sd: 810cm^2 | 810cm^2 Vas: 70.4 l | 70.4 l Spl: 86.4dB 1W/1m | 86.5dB 1W/1m Bl: 13.7 N/A | 19.1 N/A Xmax: 33mm | 33mm Rms: 3000W | 3000W Sealed box: 2-3.5cuft | 2-3.5 cuft Ported box: 3-5cuft | 3-5cuft Sub OD: 15.625” | 15.625” Cut ID: 14.125” | 14.125” Mounting depth: 11.250” | 11.250” Displacement: 0.21cuft | 0.21cuft
The SP4 Series is the latest in the progression of Fi subwoofers geared towards thundering daily drivers. Starting with a monster 4" voicecoil for increase thermal capacity, we built the rest of the sub around that. With a proprietary US made steel machined in house on one of our CNC machines, there is no shortage of motor force in the FEA derived design. With a solid pole and the optional cooling systems, there is plenty of thermal capacity in the SP4. Two high grade magnets provide the Gauss while 5 Fi designed 10" progressive spiders keep things under mechanical control. Utilizing a special 144 tinsel count leadwire there are no losses with power transfer to the coil. The 2012 SP4 Series is designed for monster daily driving systems requiring high linearity and extreme power handling. The SP4 Series raises the bar for the industry...again.
3. Description/Condition:
Mech 10/10, Cosmetic 9/10 just because not New. I got it in a trade but I dont really need it. (Drescription and condition is imho, Please check the pics because thats what you'll be getting)
4. Price:
I would like to get $350 Plus real shipping, (please don't ask me whats the lowest price I would do because I don't play that game, If you have an offer just pme)
NO TRADES! NO TRADES! NO TRADES!
5. Pictures:
(List pictures in this section, 1st picture should be your username/date if you have less than 10 positive feedbacks with the i-Trader system or less than 10 references that you have sold to in the past. (These must be listed in your signature, or a link provided to a feedback thread listing these references)).
