Item(s) for Sale:
10" TC9 Single 4ohm
Item(s) Description/Condition:
Flawless BNIB top assembly, never mounted. I mounted it to a motor from an Eclipse SW8200. Why? Because it has two 1" slugs and a huge copper ring down in the motor. Which means one very powerful, low distortion 10". Would work great in a very tiny sealed enclosure but I would throw this in a vented enclosure tuned to 25-28Hz and give it 800-1200w. Would be loud, low and clean. Driver looks phenomenal but I should note there is a bit of epoxy left on the motor from removing the heatsink. A bit of wire wheel would make quick work of it.
Qts0.298 Qes0.322 Qms4.101 Fs24hz Res3.12Ω Ls2.35mH Lp5.67mH Rp4.68Ω Dia202mm Vas31.3l mms205g cms 216um/N bl 17.2T*m Spl83dB
Price:
$200 shipped, CONUS
Shipping and Miscellaneous Item Information:
UPS
Item Pictures:
10" TC9 Single 4ohm
Item(s) Description/Condition:
Flawless BNIB top assembly, never mounted. I mounted it to a motor from an Eclipse SW8200. Why? Because it has two 1" slugs and a huge copper ring down in the motor. Which means one very powerful, low distortion 10". Would work great in a very tiny sealed enclosure but I would throw this in a vented enclosure tuned to 25-28Hz and give it 800-1200w. Would be loud, low and clean. Driver looks phenomenal but I should note there is a bit of epoxy left on the motor from removing the heatsink. A bit of wire wheel would make quick work of it.
Qts0.298 Qes0.322 Qms4.101 Fs24hz Res3.12Ω Ls2.35mH Lp5.67mH Rp4.68Ω Dia202mm Vas31.3l mms205g cms 216um/N bl 17.2T*m Spl83dB
Price:
$200 shipped, CONUS
Shipping and Miscellaneous Item Information:
UPS
Item Pictures:
