Sold 10" Custom Arsenal Subwoofer - Dual 4

[TeamPSI 10+ year member]

This subwoofer is a completely custom, one of a kind, unit. It was assembled from an Arsenal motor assembly and a 10" 12 spoke frame.

Parts used are:

2.5" 4 layer voice coil

8" x 2.5" Linear Roll spider

Sewn-on leadwire

10" Heavy Duty cone assembly

6" Poly-P dustcover

RMS Power Handling - 500w rms

For use in sealed or ported applications!

Revc = 8.1512 ohms

Fms = 35.8808 Hz

Zmax = 68.3342 ohms

Qes = 0.6856

Qms = 5.0616

Qts = 0.6038

Le = 3.5454 mH (at 1 kHz)

Diam = 210.8200 mm ( 8.3000 in )

Sd =34907.0802 mm^2( 54.1061 in^2)

Vas = 27.2466 L ( 0.9622 ft^3)

BL = 18.3046 N/A

Mms = 124.9962 g

Cms = 157.4056 uM/N

Kms = 6353.0137 N/M

Rms = 5.5673 R mechanical

Efficiency = 0.1725 %

Sensitivity= 84.3861 dB @1W/1m

Sensitivity= 84.3048 dB @2.83Vrms/1m

More pics available...

$120 shipped

Click to read more...



[TeamPSI 10+ year member]

Sold



[michaellane 5,000+ posts]

what kind of output would u expect with these?
