link
---------- Post added at 07:30 AM ---------- Previous post was at 07:29 AM ----------
linkhttp://
www.sonicelectronix.com/item_430_Kenwood-KAC-8401.html
---------- Post added at 07:30 AM ---------- Previous post was at 07:30 AM ----------
The KAC-8401 is a multi-channel power amplifier that's powerful enough and versatile enough to run almost any speaker configuration. Power output is 60 watts x 4, 180 watts x 2 (bridged), with a maximum outpu rating of 640 watts. The power MOSFET switching power supply uses two large secondary capacitors and a large toroidial noise filter. Features include selectable +6dB bass boost (90Hz), variable low-pass and high-pass electronic crossovers for the A and B channels, 2-ohm stability, speaker level inputs, a Quiet Turn-On circuit, and a cast aluminum heat sink with sandblast finish.
FEATURES
Cast Aluminum Heat Sink: with Sandblast Finish
Power Indicator: Blue Logo Triangle
Bridged Power Output at 14.4V (1kHz, 0.8% THD): 180 Watts x 2
Maximum Output Power (Bridged): 640 Watts
Power Output at 2 Ohms, at 14.4V (1kHz, 0.8% THD): 90 Watts x 4
Power Output at 4 Ohms, at 14.4V (20Hz-20kHz, 0.08% THD): 60 Watts x 4
4, 3, or 2 Channels of Amplification
Ground Isolation Circuit
Input Selector: AB/A (Common)
Quiet Turn-On
RCA Audio Inputs: Gold-Plated
RCA Line Outputs: Gold-Plated
Speaker Connectors: Gold-Plated, Screw-Type
Speaker Level Input Terminals: Plug-Type
Stereo, Left + Right, Mono, or Tri-Mode Operation
Variable High-Pass Electronic Crossover: 50Hz - 200Hz, 12dB per Octave, A and B Channel
Variable Low-Pass Electronic Crossover: 50Hz - 200Hz, 12dB per Octave, A and B Channel
Bass Boost: Off/+6dB (90Hz)
2-Ohm Stable
Copper EE-Core Power Transformer
Noise Supression Filter: Toroidal
Power Input Terminals: Gold-Plated, Large Screw-Type
Power MOSFET Switching Power Supply
Power Supply Fuse: 40A
Secondary Capacitors: 2
1-year
SonicElectronix.com warranty
