Item(s) for Sale:
Pair of T3 Audio T.1000 10" subs
Birch box
Item(s) Description/Condition:
2. Specs:
Subs
High End Performance
Offering features only normally found on elite high end drivers, the T.1000 series is an amazing subwoofer that handles up to 2,000 watts of peak music power. It offers an FEA optimized 240 oz. polished chrome plated and precision CNC machined motor assembly, heavy duty die cast aluminum coated frame and features proprietary extreme excursion twin conex spider suspensions. With their stitched-into-spider high amperage tinsel leads, black anodized 2.5” aluminum formers and dual 4 ohm hi-temp copper voice coils, the T.1000 series subwoofers will impress even the most discriminating of engineers and audiophiles.
Design
10”, 12” and 15” Subwoofers
Chrome plated 240oz. motor structure
T3 logo machined into back plate
T3 logo embossed rubber magnet boot
Unique cast aluminum basket
Rubber mounting top gasket with T3 logos
Dual spaced Conex spider suspension
T3 embossed spider spacer ring
Heavy gauge flat wire sewn in tinsel leads
Nickel plated push terminal connections
Treated multi layer EES foam surround
1 Piece Kevlar front cap with aluminum logo
Dual 4ohm Voicecoil
2.5” Black anodized aluminum coil former
Copper round wire coil 40mm height
1000w RMS/ 2000w Peak
Parameters
T.1000-10d
Fs (Hz) 37
Qes 0.79
Qms 10.13
Qts 0.73
Vas (ft3) 0.26
Spl @ 1watt (dB) 87.56
X-max (Inches) 0.80
X-mechanical (inches) 2.50"
Re (Ohms) 2 * 4.36
Pe (RMS Watts) 1000
Piston Diam. (inches) 8.25
Sd ( in2) 53
BL 26
Le (mH) 1.36
Mms (grams) 220
Rms 6.95
Cms 43.61
Zmax (Ohms) 30.32
Specifications
T.1000-10d
Total Weight (lbs) 20
Motor Weight (oz) 240
Mounting Depth 6.40"
Basket Depth 3.90"
Magnet Depth 2.50"
Cutout Diameter 9.25"
Overall Diameter 10.80"
Magnet Diameter 6.80"
Spider Diameter 8.50"
Coil Diameter 2.50"
Displacement (ft3) 0.15
Enclosures
T.1000-10d
Sealed 0.8
Vented 1.7
Vent Diameter 4"/ 13in2
Vent Length 16"
Box
Birch construction
Sealed alignment
1.6ft^3 net stuffed with poly fill
Double front baffle with flush mount
T3 audio logo in raised lettering on the back
Brushed nickel screw down binding post terminal cup.
Charcoal colored carpet
3. Description/Condition:
Subs were bought new direct from T3 in January and were used in this box only of a DD M2 amp at 1ohm for approx 3 weeks
Box was built by me for these subs.
Price:
$400 + shipping
Shipping and Miscellaneous Item Information:
Subs will ship in original retail boxes and then double boxed, the same way T3 shipped them to me, the box will ship separately in it's own box.
Item Pictures:
(List pictures in this section, 1st picture should be your username/date if you have less than 10 positive feedbacks with the i-Trader system or less than 10 references that you have sold to in the past. (These must be listed in your signature, or a link provided to a feedback thread listing these references)).
