Sold Phoenix Gold ZX475Ti Zeropoint ALMOST MINT! Crazy good SQ

[jdubbau 10+ year member]

1. Product: Phoenix Gold ZX475Ti Zeropoint Comes with manual too.

2. Specs:

ZX475Ti

Into 4 ohms Stereo @ 12.5 Vdc (IASCA/USAC) 18 x 4

Into 4 ohms Stereo @ 14.4 Vdc 75 x 4

Into 2 ohms Stereo @ 14.4 Vdc 150 x 4

Into 4 ohms Bridged @ 14.4 Vdc 250 x 2

Minimum Speaker Load, Bridged 2 ohms

Minimum Speaker Load, Stereo 1 ohm

Recommended Fuse Size, Stereo 4 ohms / Stereo 2 ohms / Bridged 60 / 80 / 80 amp

Continuous Current Draw @ Full Power * 60 amps

Peak Current Draw @ Full Power ** 85 amps

Dimensions, Chassis (inches) 15.00 L x 9.00 W x 2.25 H

Dimensions, Overall (inches) 16.00 L x 10.00 W x 2.25 H

Total Harmonic Distortion

Signal to Noise Ratio (A-weighted) > 100 dB

Frequency Response +/- 1 dB, 20 Hz to 20 kHz

Bass Boost 0 to +18 dB @ 45 Hz

Crossover Frequency Range 40 Hz to 8 kHz

Crossover Slope 24 dB per octave

Input Sensitivity 200 millivolts to 6 volts

Input Impedance > 30 kohms

Input Voltage Range 0.2 volts to 6 volts

Power Supply Operating Range 10.5 Vdc to 15.5 Vdc

Typical current draw at idle

3. Description/Condition:

10/10 Mechanical and 9.5/10 Cosmetic great condition.

4. Price: : $190 Shipped in Con US

5. Pictures:

Click to read more...



[supermaxx123 10+ year member]

how do you run 3-way active with a 4ch amp?



[jdubbau 10+ year member]

I believe I MEANT 3 way mode. THX

This amp does ALLOW many different set ups though and I DID THINK that I saw it will allow 3 way Active but now looks like it was 3 way MODE.

Some variations of set ups ON THE BACK of amp



[jdubbau 10+ year member]

Offers



[jdubbau 10+ year member]

soldd!!!
