Hey everyone,

We are opening the pre-order on the PAX Pro Audio line this morning which is expected to arrive November 15th, and that is a VERY solid ETA. These are super high quality Pro Audio speakers and you guys will be very pleased with how loud and great they sound.

ETA : 11/15/2012

Magnet Type : Neodymium

Available Coils : Single 4 / 8 Ohm

Voice Coil : 2"

RMS Power : 6.5" - 150 Watts

8"/10" - 260 Watts

These are sold individually, and prices reflect that.

Pricing (Free Shipping)

6.5" (4/8 Ohms) = $70.00 EA (Normal MAP - $99.99 EA)

8" (4/8 Ohms) = $80.00 EA (Normal MAP - $104.99 EA)

10" (4/8 Ohms) = $95.00 EA (Normal MAP - $129.99 EA)

How To Pre-Order!

It is quite simple to pre-order. All you have to do is visit the PAX Section on the Skar Audio website by clicking this link below and you will see a PayPal option which allows you to choose the size/qty/voice coil of the PAX you would like to pre-order!

>>> Click Me To Pre-Order

watch


Pictures








Last edited by a moderator:
Email kevin@skaraudio.com to discuss multiple qty pricing discounts - sorry we were extremely busy last few days haven't been on the forum as much as we wanted. We will take care of you if you email us though!

T/S parameters are posted on Welcome to Skar Audio under the PAX Section which can be found under products.



---------- Post added at 08:25 PM ---------- Previous post was at 08:24 PM ----------



And yes we will be launching 3 pro audio tweeters in late January, but we will announce more on those next month.


Mounting Specifications

PAX-6.5"

Mounting Depth : 3.1"

Cut-Out Diameter : 5.8"

Outside Diameter : 6.6"

PAX-8"

Mounting Depth : 3.6"

Cut-Out Diameter : 7.2"

Outside Diameter : 8.3"

PAX-10"

Mounting Depth : 4"

Cut-Out Diameter : 8.7"

Outside Diameter : 10"


Here is a Rpost from SSA from one of the lead tech guys over there.. Here is what he had to say about the "pro audio" from them.

"The PAX-6.5, for example.

Re of 4ohms? I've never seen a speaker with an Re of 4ohms....nominal impedance, yes. But not Re. I'm going to presume it's 4ohm nominal and it's Re is somewhere in the 3.X range?

Second, a Qes of 1.758 and a Qts of .412 ? Even with nothing but a rudimentary understanding of T/S we can tell those numbers don't match up. Qes is the main determinant of Qts....those two numbers should be much closer. Qts should be more in the vicinity of 1.4

You list No as .19% and SPL 89.8db. Based on the listed Fs, Qes and Vas the No calculates out to be 1.28% and SPL 93db. A No of .19% would equate to a sensitivity of 84.8db, not 89.8db. So, in short, none of those numbers match up.

Your units for compliance are wrong, or your decimal is in the wrong spot. I'm assuming it's really .090742 mm/N

Based on the listed Vas and Cms, the Sd would be around 446cm^2, which is not much smaller than a 12" driver and obviously not correct.

Based on Mms and Cms, Fs should be 126hz, not 97hz.

That's not an all encompassing list, but a brief summary. In short.....those parameters are physically impossible and make no sense together whatsoever. "
