SOLD Own a piece of Ngsm13's History

[Darren5531 10+ year member]

Here is your chance to own a little bit of ngsm13's history. This subwoofer was featured in this reconeing thread as seen on this site.

Mainly looking for trades on either a active head unit, 1 or 2 subs depending on what kind and maybe a 4 channel amp. I would love to get a pair of idqs/idoems, diymas or dayton ho's. Here is how ngsm13 himself would describe the woofer.

It would be on par with a W7 and IDmax... and it's very efficient.

I would put it right at 50/50 sq/spl... a great SQ subwoofer. Excellent SQ, with great output due to linear displacement.

I'd put above the performance of an oldschool SI Magnum

I am wanting $220+exact shipping. This is a steal because whatever ngsm13 touches automatically jumps up to a $500 value.

Specs:

15" Custom Black Ash 12 spoke Basket

Dual 2ohm 3" Voice Coil

Dual Stiff Spiders

Zinc Plated Push Pin speaker terminals

26mm Xmax

Revc = 3.4800 ohms

Fs = 31.6602 Hz

Zmax = 42.0942 ohms

Qes = 0.6016

Qms = 6.6755

Qts = 0.5519

Le = 3.7553 mH (at 1 kHz)

Diam = 365.1250 mm ( 14.3750 in )

ConeArea =104706.3470 mm^2(162.2952 in^2)

Vas = 116.1551 L ( 4.1020 ft^3)

BL = 19.3946 N/A

Mms = 330.7339 g

Cms = 75.4348 uM/N

Kms =13256.4746 N/M

Rms = 9.7239 R mechanical

Efficiency = 0.5907 %

Sensitivity= 89.7134 dB @1W/1m

Sensitivity= 93.3285 dB @2.83Vrms/1m

Saved the best for last pictures:

Click to read more...



[ngsm13 5,000+ posts]

Lol.

Good luck with the sale!

nG



[Darren5531 10+ year member]

//content.invisioncic.com/y282845/emoticons/cool.gif.3bcaf8f141236c00f8044d07150e34f7.gif Even with ngsm13's own seal of approval.



[keefy248 10+ year member]

nice whats the ratings.



[bdawson72 5,000+ posts]

Doesnt that have a mag motor



[HawaiianBassHed 10+ year member]

probably an upgrade as far as coil and suspension would be my guess if it is, that's what would make it better than the "old" mag imo



[Darren5531 10+ year member]

Power wise you should be great anywhere from 600-1300+ rms but only go that high if you know what your doing. 900-1200 rms would be optimal in either a nice 2 cube box with some poly fill or a nice ported box would make it sing. Yes Hawaiianbasshead Ngsm13 said he would probably rate it above an old school magnum because of the copper wires and upgraded suspension.



[Propimp 10+ year member]

i want want. i have to wait untill i get home to see pics. im at work and cant see them ;(



[99gtxgolfer 10+ year member]

nice



[Darren5531 10+ year member]

Propimp you have pm.

Yes it is nice. //content.invisioncic.com/y282845/emoticons/smile.gif.1ebc41e1811405b213edfc4622c41e27.gif



[BassAce 10+ year member]

WOW, by ngsm13. Who's that, never heard or seen him.



[Blunt 10+ year member]

Doesnt that have a mag motor

yes it's a tc9



[ngsm13 5,000+ posts]

It's a modified TC9. Larger slugs, more motor strength that a stock TC9.

//content.invisioncic.com/y282845/emoticons/fyi.gif.9f1f679348da7204ce960cfc74bca8e0.gif

nG



[Darren5531 10+ year member]

Thanks ng



[req 5,000+ posts]

looks like a no name brand.

//content.invisioncic.com/y282845/emoticons/rolleyes.gif.c1fef805e9d1464d377451cd5bc18bfb.gif

and who is this guy who owned it? is he some sort of pedophile?
