MX Designs Amplifiers by CDT Audio - New Line


trumpet

Barry Schanz
Jan 3, 2011
6,942
17
Grafton, ND
CDT Audio Introduces 3 New Amplifiers



Prices, hands-on look and listening notes coming soon.

The first shipment is selling fast! PM me to lock in your order.


OP
trumpet

trumpet

Barry Schanz
Jan 3, 2011
6,942
17
Grafton, ND
CDT Audio MXMA-1502



Features:

  • 12 dB/octave crossover
  • Variable high pass crossover (30 Hz - 500 Hz)
  • Variable low pass crossover (30 Hz - 500 Hz)
  • Variable 0 dB to 12 dB Bass EQ centered at 45 Hz
  • Input Sensitivity from 6V to 0.2V
  • 5 Way Protections
  • Output RCA jacks for daisy chain operation
  • Power and Protect LED
  • 2 Ohm Stable
  • Soft start/mute circuit
  • Remote gain control(only active with Low Pass Filter enabled) with power LED
  • High level (speaker level) inputs


Technical Specifications:

  • 100W x 2 @ 4 ohms, 14.4V
  • 150W x 2 @ 2 ohms, 14.4V
  • 300W x 1 @ 4 ohms bridged, 14.4V
  • S/n ratio: > 95 dB
  • THD (IHF-A): 0.05%
  • Input impedance: 20 Kohm
  • Slew rate: 10V / Usec
  • Damping factor: >100
  • Fuse rating: 40A
  • Dimensions: 139.5mm W x 46.7mm H x 220mm L


http://store.513electronics.com/cdt-audio-mxma-3001/

CDT Audio MXMA-3001



Features:

  • 12 dB/octave crossover
  • Variable low pass crossover (30 Hz - 500 Hz)
  • Variable 0 dB to 12 dB Bass EQ centered at 45 Hz
  • Input Sensitivity from 6V to 0.2V
  • 5 Way Protections
  • Output RCA jacks for daisy chain operation
  • Power and Protect LED
  • 2 Ohm Stable
  • Soft start/mute circuit
  • Remote gain control with power LED
  • High level (speaker level) inputs


Technical Specifications:

  • 220W x 1 @ 4 ohms, 14.4V
  • 350W x 2 @ 2 ohms, 14.4V
  • S/n ratio: > 95 dB
  • THD (IHF-A): 0.05%
  • Input impedance: 20 Kohm
  • Slew rate: 10V / Usec
  • Damping factor: >100
  • Fuse rating: 40A
  • Dimensions: 139.5mm W x 46.7mm H x 220mm L


http://store.513electronics.com/cdt-audio-mxma-7504/

CDT Audio MXMA-7504



Features:

  • 12 dB/octave crossover
  • Variable high pass crossover (30 Hz - 500 Hz)
  • Variable low pass crossover (30 Hz - 500 Hz)
  • Variable 0 dB to 12 dB Bass EQ centered at 45 Hz
  • Input Sensitivity from 6V to 0.2V
  • 5 Way Protections
  • Output RCA jacks for daisy chain operation
  • Power and Protect LED
  • 2 Ohm Stable
  • Soft start/mute circuit
  • High level (speaker level) inputs


Technical Specifications:

  • 50W x 4 @ 4 ohms, 14.4V
  • 90W x 2 @ 2 ohms, 14.4V
  • 160W x 2 @ 4 ohms bridged, 14.4V
  • S/n ratio: > 95 dB
  • THD (IHF-A): 0.05%
  • Input impedance: 20 Kohm
  • Slew rate: 10V / Usec
  • Damping factor: >100
  • Fuse rating: 40A
  • Dimensions: 139.5mm W x 46.7mm H x 220mm L



remote gain knob with power LED
