Megalomaniac - By Request - SketchUp - Port Elbow Tutorial

[Mr Cabinetry 10+ year member]

I can't make it any simpler than that.

Phil

Woodlawn Cabinetry

Click to read more...



[lilmaniac2 5,000+ posts]

follow me tool is so ftw



[Megalomaniac 5,000+ posts]

Thank you Mr.Cab!



[dragnix 5,000+ posts]

ok, now do one for autocad //content.invisioncic.com/y282845/emoticons/tongue.gif.6130eb82179565f6db8d26d6001dcd24.gif



[Mr Cabinetry 10+ year member]

ok, now do one for autocad //content.invisioncic.com/y282845/emoticons/tongue.gif.6130eb82179565f6db8d26d6001dcd24.gif

Don't have AutoCad, nor do I need it for any particular reason, nor would I spend $ 450.00 for it, besides, anyone that has autocad and has the capabilities to use should be a piece of cake for them to draft something as simple a 4" 90 degree elbow.
