How do you Ground RCA's of the Head Unit???

[swollen_cu 10+ year member]

How do you Ground RCA's of the Head Unit?

Click to read more...



[stanky1219]

take a ground wire and wedge it in the outer rim of the rca plug as you plug it in making sure not to touch the + lead on the rca.

i had to do that on a few pioneer decks that were really noisy for some reason.



[swollen_cu 10+ year member]

I'm using all three pairs of my pre outs. So I have to do it to all 6 plugs?

That's alot of messy wires. Lol



[swollen_cu 10+ year member]

So do i ground each of the 6 RCAs or just do it to one?



[CoilBurner]

All 6 get grounded, either to the chassis of the h/u or to a ground on your car.

You dont have to use wire this thick as in the pic, but you can see it isnt a big mess, just make sure your rca's can plug back in perfect, and your ground wire around the rca connects are tight enough to make good contact. Only takes a half hour and gets rid of the problem...... FO - EVA



[Sleeklsc 5,000+ posts]

my pioneer unit had the extention for the rca's.(unlike the one above) i plugged in all 3 sets of rca's and wrapped wire around each one and grounded similiar to the one above.. pretty much the same concept though. worked great for me.



[swollen_cu 10+ year member]

my pioneer unit had the extention for the rca's.(unlike the one above) i plugged in all 3 sets of rca's and wrapped wire around each one and grounded similiar to the one above.. pretty much the same concept though. worked great for me.

I also have the extension for the RCA's and did the same thing you did.

The noise got a little bit better, but there's still a little bit of whine noise.

Can it be anything else? Thanks



[Ryan LaPlante]

I also have the extension for the RCA's and did the same thing you did.

The noise got a little bit better, but there's still a little bit of whine noise.

Can it be anything else? Thanks

I had to ground my HU to the same point my amps are grounded to get rid off the noise in my system, I would just run a test wire than route it officially if that gets rid if the last bit of alt whine.



[Popwarhomie 5,000+ posts]

I had to ground my HU to the same point my amps are grounded to get rid off the noise in my system, I would just run a test wire than route it officially if that gets rid if the last bit of alt whine.

Only 15 years late with that reply.....



[Mitchell Fosgate III]

According to quora, not need to ground any RCA cables not connected to other devices. Like a module. Internally grounded. If you did ground it, did you place it on the chassis or box? Noise reduction wire is inside the RCA cables.
