Item(s) for Sale: Image Dynamics Q450.4 4 channel amplifier
Item(s) Description/Condition:
Used in 10/10 condition. only used for about three months. going a different route to a 5ch amplifier. I LOVE this amp. by far a great contender for high quality sound reproduction. I love the bandpass feature as well.
Price: $325 Shipped and insured OR trade straight up + a little cash from my end for a high quality 5ch. amplifier that has a bandpass feature as well as a sub channel that can do 400-600rms@2ohms
Shipping and Miscellaneous Item Information:
via fedex
Item Pictures:
(List pictures in this section, 1st picture should be your username/date if you have less than 10 positive feedbacks with the i-Trader system or less than 10 references that you have sold to in the past. (These must be listed in your signature, or a link provided to a feedback thread listing these references)).
Item(s) Description/Condition:
Used in 10/10 condition. only used for about three months. going a different route to a 5ch amplifier. I LOVE this amp. by far a great contender for high quality sound reproduction. I love the bandpass feature as well.
Image Dynamics Q450.4 (Q4504) 4-Channel Class A/B Q Car AmplifierPer sonicelectronix website:Specs:
Q Series 4-Channel Class A/B Car Amplifier
RMS Power Rating (14.4V):
4 ohms: 75 watts x 4 chan.
2 ohms: 100 watts x 4 chan.
Bridged, 4 ohms: 200 watts x 2 chan.
Optically isolated MOSFET power supply
LED power indicator
Fixed Bass Boost (+12 dB bass boost at 40 Hz)
Soft Start Turn-on
4/3/2 Channel operation
Bridgeable Capability
Band pass crossover on front channels
Bi-Polar High-current output devices
Auxiliary full range output
Two-layer PC Board with heavy 2 oz copper
Massive ground planes and precision caps
3-Way System Protection circuitry (thermal, overload, and speaker short protection)
Heavy duty aluminum alloy heatsink for extreme heat dissipation
Nickel-plated RCA level inputs
Nickel-plated screw terminals
Input sensitivity:
Low level: 150mV-5V
Variable low-pass filter (50-5000 Hz, 12 dB/octave)
Damping factor: >100
In-line fuse requirement: 80 amps
Frequency response: 10-30,000 Hz
Signal-to-Noise ratio: 100dB
Dimensions: 13.0"L x 8-1/2"W x 2-1/4"H
My review I did:
I purchased this amplifier to swap with a Rockford Fosgate "T" series amplifier. Night and day difference. The Amplifier produces a very crisp clean signal. Clamped number per channel are as follows for my setup:
Ch.1 and 2 - 84w @ 3.6ohm - Midbass drivers
Ch. 3 and 4 - 82w @ 3.8ohm - Tweeters
So therefore the amplifier is slightly under rated. Using the on board crossover features the amplifier is running four midbass drivers and 4 tweeters. Very detailed midbass from 50hz and up unlike the rockford which lacked anything and had distortion below 120hz. With small amounts of amperage draw at high volumes this amplifier is a great factory add on. It looks very sleek as well.
My only con would be it has close to no heat sync fins to help with cooling. With that said mount this amplifier with ample airflow!
Price: $325 Shipped and insured OR trade straight up + a little cash from my end for a high quality 5ch. amplifier that has a bandpass feature as well as a sub channel that can do 400-600rms@2ohms
Shipping and Miscellaneous Item Information:
via fedex
