Item(s) for Sale:
Image Dynamics Q1200.1!
Item(s) Description/Condition:
used BUT MINTY! I need like 2500rms @1ohm so selling this to fund buying a new amp. Talked to a guy at Image Dynamics and he said amps runs a wee bit warm as its A/B but is amazing on power. does over any power rating in the specs listed below. how much over im not sure. its amazing quality. MADE IN KOREA! Comes with Bass knob!
Class A/B Mono-Channel Amplifier
Audiophile Grade NE5532 Opamps
Mosfet power supply
1Ohm stable high current design
High current bi-polar output design
Soft start / mute circuit
Remote bass level control
Fully-Variable Phase shift
input: 2 channel RCA style differential balanced mode
Channels 1&2 Crossover: Fully-Variable 50~250Hz (12 db per octave ) LP
Sub Sonic Filter: Fully-Variable 15~45Hz ( 12 db per octive )
Channels 1&2 Bass Eq: Fixed at 40Hz with 12db of boost
input Sensitivity: 150mV~5.0V RMS
input Impedence: 20K ohms
rated power ( Mono ) : 500 watt @ 4 ohm ( 14.4 VDC )
rated power ( Mono ) : 800 watt @ 2 ohms ( 14.4 VDC )
rated power ( Mono ) : 1200 watt@ 1 ohm ( 14.4 VDC )
Frequency Response ( All channels ): 10Hz~30KHz +/- .5db
THD + Noise ( All channels ): S/N Ratio ( All channels ): >100db
Damping factor @ 50hrz: >100@2 ohms
All speaker outputs connections: Accept up to 8 AWG wire
power input and ground connections: Accept up to 4 AWG wire
Dimensions ( L x W x D ) 18.5 in. x 8.625 in. x 2.0625 in.
470 mm x 219 mm x 52.3 mm
Price:
$300
Shipped OBO!
Shipping and Miscellaneous Item Information:
via fedex. included in price
Item Pictures:
guts
(List pictures in this section, 1st picture should be your username/date if you have less than 10 positive feedbacks with the i-Trader system or less than 10 references that you have sold to in the past. (These must be listed in your signature, or a link provided to a feedback thread listing these references)).
