Sold fs: 8 layer Alum flat wound coils

[ssackett 10+ year member]

1. Product:

Quad 8 layer flat wound alum coils 3" coils

2. Specs:

Black former is quad .76

OD = 3.3"

ID = 3"

WW= 1.94"

White former is quad 1.5

OD = 3.32"

ID = 3"

WW = 2.16"

3. Description/Condition: New!! Can be wired under the dustcap to run them as DVC coils.

4. Price: : $40 shipped each... Have plenty to go around..

5. Pictures:

Click to read more...



[grimreper912003 5,000+ posts]

What is the Former hight on the black former? What is the ID and OD of it? Winding Hight?



[ssackett 10+ year member]

What is the Former hight on the black former? What is the ID and OD of it? Winding Hight?

Dont have my calipers here at the house. Ill try and take the measurements tomorrow morning.



[grimreper912003 5,000+ posts]

Dont have my calipers here at the house. Ill try and take the measurements tomorrow morning. WW on the white former is about 2.1" and former hieght is 3 15/16" and the black formers ww is 2" and the former height is 4 1/16"

Alrighty. Will check back tomorrow for ID and OD. Thanks.



[matthewo 10+ year member]

the white one look like an eclipse ti pro coil, or tc sounds 4hp, which are the same thing. if so those things will handle like 5000+ for daily, i ran that much to my ti pro which had a 8 layer flat wound coil like that, and it took it without smelling



[ssackett 10+ year member]

My bad.. Forgot to post these are 3" coils.. LOL!



[godhatescivics 10+ year member]

will this fit on a solox 12 motor



[ssackett 10+ year member]

will this fit on a solox 12 motor

Hmmm I'm not sure.. I'm on my way to get some calipers. Ill have the OD and ID shortly.



[ssackett 10+ year member]

Up for specs added



[nu2spl 10+ year member]

crappy i only have dual coil motors,bump for you



[ssackett 10+ year member]

crappy i only have dual coil motors,bump for you

Wire the coils under the dustcap for the final load you want if you dont want to run it as a quad. Just make sure to use jumpers with a jacket or heat shrink so you dont cross any wires!! HAHAHA!!



[PBateman 10+ year member]

will this fit on a solox 12 motor

The solox subs use a 3.5" coil. **** Scott, you should of told me about these the other night. Call me tomorrow and i'll take a few of each.



[nu2spl 10+ year member]

Wire the coils under the dustcap for the final load you want if you dont want to run it as a quad. Just make sure to use jumpers with a jacket or heat shrink so you dont cross any wires!! HAHAHA!!

no i cant,my gap isnt wide enough



[PBateman 10+ year member]

crappy i only have dual coil motors,bump for you

Are you thinking because they were dvc before that's what you have to use to recone them? What motors?



[nu2spl 10+ year member]

Are you thinking because they were dvc before that's what you have to use to recone them? What motors?

no man,ive tried quads before and they wont fit.
