so i have an RD 7500.1 that i have not used since i bought it off ss audio mike. i was planning on using it in my truck but since a deer blasted the side of my truck i need to get this gone.
SPECS off thier site
This is a Competition only amplifier and we do not recommend it for daily applications due to its massive power output and current draw.
Recommended power supply– A minimum of six group 31 batteries and a high output alternator.
The RD series amplifiers deliver a ton of power with a low distortion rate. We used the best parts we could find to give you a top quality amplifier that anyone would be proud to show off. With their clean looks and sleek finish, they’ll look good in any install. So whether it’s an elegant sound quality setup or a high powered SPL vehicle, the RD series amplifiers have you covered.
Features
* Digital class-D linkable mono block amplifier
* MOSFET PWM power supply
* Daisy-chain through output RCA
* Heavy duty cooper layer double sided epoxy PCB
* Stable into 1 ohm and 2 ohm parallel amplifier connection availability
* 24 dB low pass (LPF) crossover variable
* 18 dB bass boost equalization control variable
* 180 degree variable adjustable phase shift
* 24 dB subsonic filter variable
* Selectable Switch for MASTER and SLAVE Operation
* Speaker short, over current, thermal, and DC protection circuit
* RCA line input and line output
* 2 x 0 guage (AWG) battery input connectors
* Efficiency: 86% at 4 ohm, 100 Hz
* Tested voltage & THD : 14.4V and less than 1% THD at 4 ohm RMS watt
* Operating voltage: DC 10V ~ 18V power input
* Damping factor: better 350 into 1 ohm
* Wired remote controller
MSRP
$2899.00
Specifications
RMS power, .875 ohms mono 7500w X 1CH
RMS power, 1 ohm mono 6000w X 1CH
RMS power, 2 ohm mono 3000w X 1CH
RMS power, 4 ohm mono 1500w X 1CH
Signal to Noise Ratio >100dB
Low pass frequency crossover 35Hz~300Hz
Subsonic filter 10Hz~60Hz
Bass boost @ 45Hz 0~18dB
Phase shift control 0~180 degree
Frequency response 10Hz~350Hz (+/- 1dB)
T.H.D @ 4 ohm
Efficiency @ 4 ohm 86%
Fuse rating 600A(external type fuse - not included)
Input Sensitivity 200mV to 6V (+/- 5%)
Dimensions 222(W) x 52(H) x 870(L)mm
pics -
this is the only problem i see with this case just a little ding on the corner
850+ ship
