Sold F/S 2 Dayton RS225-4 8" woofers

Tacosys
10+ year member

CarAudio.com Elite
Rating: 0%
0 0 0
Asking $70 shipped for the pair, one is less than a week old, the other is probably 6 weeks old.

Here are the specs, I will have pics up in a few minutes.

The Dayton Reference Series sets a new standard of value in high-performance loudspeaker drivers. Utilizing a low-distortion motor system with two short-circuit paths and a rigid aluminum cone, the Reference Series can outperform drivers that cost several times the price. Their low-distortion characteristics and high excursion capabilities provide exceptional clarity, detail, and dynamics. Woofer features a black anodized cone, heavy-duty 6-hole cast frame, low-loss rubber surround, solid aluminum phase plug, rubber magnet boot, and gold spring terminals.

Specifications: *Power handling: 80 watts RMS/120 watts max *VCdia: 1.5" *Le: .50 mH *Impedance: 4 ohms *Re: 2.9 ohms *Frequency range: 40-2,000 Hz *Fs: 42 Hz *SPL: 92 dB 2.83V/1m *Vas: 1.08 cu. ft. *Qms: 2.55 *Qes: .60 *Qts: .49 *Xmax: 6 mm *Dimensions: A: 8-3/4", B: 7-3/8", C: 3-1/2".


Link for pic, I don't feel like pulling my door panels off tonight:

http://www.partsexpress.com/pe/showdetl.cfm?Partnumber=295-376




I need the rings! I will make you a stencil of them though for free //content.invisioncic.com/y282845/emoticons/biggrin.gif.d71a5d36fcbab170f2364c9f2e3946cb.gif
