BNIB Scan-Speak 25W/5565A00 4-Ohm - $275 shipped
I bought these 10" drivers to play midbass duty (50-600hz) in a 3-way frontstage but realized that I dont have the time to complete the project. They could also be used as subwoofers. They are BNIB and optimized for car audio with 4ohm SVC in either a sealed or infinite baffle configuration Mounting depth is only 3.38" and these drivers were designed to play in 0.6 ft3 enclosures. The specs look better then the Peerless XLS drivers. They MSRP is $210/ea
http://www.d-s-t.com.au/data/ScanSpeak/25W5565A00data.pdf#search="ScanSpeak 25W 5565A00"
SPECIFICATIONS
Technical Data:
Impedance - 4 Ohm
Fs - 19 Hz
Sensitivity - 89dB (1W/1M)
Xmax - 14mm (linear, p-p)
Max. coil travel - 26mm
FR - 19-600 Hz
Le - 0.3 mH
Sd - 330cm2
BL - 10.9 Tm
Vas - 88 L
Qms - 3.01
Qes - 0.61
Qts - 0.51
Outside Diameter: 255mm (10")
Cutout Diameter: 228mm (8.98")
Mounting Depth: 86mm (3.38")
Optimized for high-end automotive applications and small 0.6 - 0.8 cubic foot (18 - 22 Litre) sealed enclosures. Can also work great IB such as doors //content.invisioncic.com/y282845/emoticons/wink.gif.608e3ea05f1a9f98611af0861652f8fb.gif
I bought these 10" drivers to play midbass duty (50-600hz) in a 3-way frontstage but realized that I dont have the time to complete the project. They could also be used as subwoofers. They are BNIB and optimized for car audio with 4ohm SVC in either a sealed or infinite baffle configuration Mounting depth is only 3.38" and these drivers were designed to play in 0.6 ft3 enclosures. The specs look better then the Peerless XLS drivers. They MSRP is $210/ea
http://www.d-s-t.com.au/data/ScanSpeak/25W5565A00data.pdf#search="ScanSpeak 25W 5565A00"
SPECIFICATIONS
Technical Data:
Impedance - 4 Ohm
Fs - 19 Hz
Sensitivity - 89dB (1W/1M)
Xmax - 14mm (linear, p-p)
Max. coil travel - 26mm
FR - 19-600 Hz
Le - 0.3 mH
Sd - 330cm2
BL - 10.9 Tm
Vas - 88 L
Qms - 3.01
Qes - 0.61
Qts - 0.51
Outside Diameter: 255mm (10")
Cutout Diameter: 228mm (8.98")
Mounting Depth: 86mm (3.38")
Optimized for high-end automotive applications and small 0.6 - 0.8 cubic foot (18 - 22 Litre) sealed enclosures. Can also work great IB such as doors //content.invisioncic.com/y282845/emoticons/wink.gif.608e3ea05f1a9f98611af0861652f8fb.gif
![DSC00310.jpg](/proxy.php?image=http%3A%2F%2Fi75.photobucket.com%2Falbums%2Fi313%2Fazngotskills%2FDSC00310.jpg&hash=9ba5d489d5782aabff7cc1687dc9459f)
![DSC00311.jpg](/proxy.php?image=http%3A%2F%2Fi75.photobucket.com%2Falbums%2Fi313%2Fazngotskills%2FDSC00311.jpg&hash=25d639580ec04d8d727b22d4262e5265)
![DSC00313.jpg](/proxy.php?image=http%3A%2F%2Fi75.photobucket.com%2Falbums%2Fi313%2Fazngotskills%2FDSC00313.jpg&hash=4461983a3a5b37954aed491224c51319)
