Sold BNIB LA Storm X1.525C 5 1/4" Comps

[clbolt 10+ year member]

I have a brand new set of Lightning Audio Storm X1.525C 5 1/4" components. These are the most expensive LA comps ever, and were part of the same series as the TC-built Storm subs (the baskets on these mids match the ones on the Storm subs). They're exotic for LA; not only do they have titanium tweeters, but the mids have titanium cones and solid aluminum phase plugs. These also have some massive bi-ampable passive crossovers. The grills are black chrome with a brushed aluminum ring, and the tweeter mounting hardware is black chrome as well. If the only Lightning Audio gear you've ever seen came from Wal-Mart, then you've never seen anything like these. They're rated at 100w rms and 300w peak.

Here are the complete specs:

Lightning Audio Storm X1.525C

Nominal Diameter: 5.25"

Nominal Impedance: 4 Ohms

Frequency Response: 70Hz- 20kHz

Fs (Hz):73

Sensitivity (SPL@ 1w/1m): 89.6dB

RMS Power Handling (watts continuous): 100

Power Handling (watts maximum): 300

Mounting Diameter (in): 4 11/16

Mounting Diameter (mm): 119

Mounting Depth (in): 2 1/4"

Mounting Depth (mm): 57

Tweeter

Nominal Diameter (in): 1.0"

Nominal Impedance (ohms): 4

Frequency Response: 2.5kHz- 20kHz

Fs (kHz):2.5

Sensitivity (SPL@ 1w/1m): 91dB

RMS Power Handling (with recommended filter network) 100 Watts

Crossover

Type: 2-way

Crossover Frequency: 5.4 kHz @ 4 ohms

Crossover Slope: 12dB/octave High-Pass

12dB/octave Low-Pass

Filter Q: 0.707 (Butterworth)

Tweeter Protection: Optical Compression

Dimensions (inches): 5 1/8" (W) x 6 3/16" (D) x 1 9/16" (H)

This set includes flush and surface mounts for the tweeters.

$125 shipped CONUS, PM if you're interested.

Click to read more...



[orangelss 10+ year member]

These are some very good sounding speakers. Had a pr of the 5.75 componets.



[clbolt 10+ year member]

Up^^^



[clbolt 10+ year member]

Up^^^



[clbolt 10+ year member]

If you've never seen the LA Storm comps, do a little research on them. These are some serious drivers that Fosgate happened to hang the Lightning Audio brand on. The bare mids are worth the price of admission plus some.



[clbolt 10+ year member]

Up^^^



[clbolt 10+ year member]

I didn't realize how little was published about these online, so here are the specs from the manual:

Lightning Audio Storm X1.525C

Nominal Diameter: 5.25"

Nominal Impedance: 4 Ohms

Frequency Response: 70Hz- 20kHz

Fs (Hz):73

Sensitivity (SPL@ 1w/1m): 89.6dB

RMS Power Handling (watts continuous): 100

Power Handling (watts maximum): 300

Mounting Diameter (in): 4 11/16

Mounting Diameter (mm): 119

Mounting Depth (in): 2 1/4"

Mounting Depth (mm): 57

Tweeter

Nominal Diameter (in): 1.0"

Nominal Impedance (ohms): 4

Frequency Response: 2.5kHz- 20kHz

Fs (kHz):2.5

Sensitivity (SPL@ 1w/1m): 91dB

RMS Power Handling (with recommended filter network) 100 Watts

Crossover

Type: 2-way

Crossover Frequency: 5.4 kHz @ 4 ohms

Crossover Slope: 12dB/octave High-Pass

12dB/octave Low-Pass

Filter Q: 0.707 (Butterworth)

Tweeter Protection: Optical Compression

Dimensions (inches): 5 1/8" (W) x 6 3/16" (D) x 1 9/16" (H)

This set includes flush and surface mounts for the tweeters.



[Louisiana_CRX 5,000+ posts]

if these were 6.5's i'd had to buy them...nice componets



[clbolt 10+ year member]

if these were 6.5's i'd had to buy them...nice componets

Yeah, I hate to get rid of them. I'd like to find a set if the 6.5s and build an all LA system.



[clbolt 10+ year member]

Up^^^



[clbolt 10+ year member]

Up^^^



[clbolt 10+ year member]



[clbolt 10+ year member]

Still available...



[clbolt 10+ year member]

Up^^^



[infamous_e46 5,000+ posts]

tc built ???
