Sold Audiomobile EVO 2210 S24

[audio_phill 10+ year member]

1. Product: Audiomobile EVO 2210

2. Specs:



14mm Xmax and heres the TSP's I just pulled:

Re = 5.9133 ohms

Fs = 26.6743 Hz

Zmax = 53.8656 ohms

Qes = 0.3807

Qms = 3.0871

Qts = 0.3389

Le = 5.1670 mH (at 1 kHz)

Diam = 209.5500 mm ( 8.2500 in )

Sd = .0345 m^2( 53.4562 in^2)

Vas = 57.5772 L ( 2.0333 ft^3)

BL = 16.4918 N/A

Mms = 104.4718 g

Cms = 340.7657 uM/N

Kms = 2934.5676 N/M

Rms = 5.6719 R mechanical

Efficiency = 0.2697 %

Sensitivity= 86.3272 dB @1W/1m

Sensitivity= 87.6398 dB @2.83Vrms/1m

1.2 @ 32Hz is beautiful. Output will surprise you as well, very efficient woofer. TC Sounds at its best...

3. Description/Condition:

Beautiful shape, camera accentuates the lil scratches in the cone, darn 15MP, lol I love it, just dont need it //content.invisioncic.com/y282845/emoticons/frown.gif.a3531fa0534503350665a1e957861287.gif

Trades: SW8000/8200 in similar condition or 3HP or TC3LM motor

4. Price: : $140 plus shipping

5. Pictures:

Click to read more...



[audio_phill 10+ year member]

Need money fast $120 plus shipping



[audio_phill 10+ year member]

Dont need the cash as bad so $130 plus 1/2 shipping

Buy me!



[audio_phill 10+ year member]

ttt



[audio_phill 10+ year member]

TTT again



[audio_phill 10+ year member]

Uppidy



[audio_phill 10+ year member]

Tip Top



[audio_phill 10+ year member]

Up, Awesome SQ and very respectable output off 400rms in 1.2 @ 32Hz



[audio_phill 10+ year member]

$140 Shipped Con-US, need some money again.



[audio_phill 10+ year member]

ttt



[audio_phill 10+ year member]

Up again darn it



[ciaonzo 5,000+ posts]

Up.



[ciaonzo 5,000+ posts]

Bumperz.
