Audio Technix Tropo and Strato Subwoofer Line T/S and Production Pictures

[cthedinger 10+ year member]

Subwoofers are do in stock around November 10th. All prices will be plus shipping but will be doing free shipping for the first month or two. I will also be opening up a pre-order at the end of the week. I have 2000w (Exo) that will be here around the same. I also have a very underrated 800w sub in the works and am hoping to bring it out in the late winter.

Tropo-10D4 - 2” voice coil – MAP $89.99

Re: 8.0 ohms

Fs: 29.4 Hz

VAS: 46.1 L

Le: 2.87 mH

BL: 18.4 NA

Qes: 0..47

Qms: 4.82

Qts: 0.43

Mms: 106.7 g

RMS: 200 Watts

Tropo-12D4 – 2” voice coil – MAP $99.99

Re: 8.0 ohms

Fs: 32.3 Hz

VAS: 71.1 L

Le: 2.77 mH

BL: 17.2 NA

Qes: 0.68

Qms: 4.51

Qts: 0.59

Mms: 124.4 g

RMS: 200 Watts

Strato-10D2 – 2.5” voice coil – MAP $114.99

Re: 4.0 ohms

Fs: 34,2 Hz

VAS: 20.2 L

Le: 1.75 mH

BL: 15.4 NA

Qes: 0.47

Qms: 4.43

Qts: 0.43

Mms: 130.9 g

RMS: 400 Watts

Strato-10D4 – 2.5” voice coil – MAP $114.99

Re: 8.0 ohms

Fs: 32,1 Hz

VAS: 38.5 L

Le: 2.95 mH

BL: 19.3NA

Qes: 0.47

Qms: 4.15

Qts: 0.43

Mms: 107.1 g

RMS: 400 Watts

Strato-12D2 – 2.5” voice coil – MAP $139.99

Re: 4.0 ohms

Fs: 32.7 Hz

VAS: 112.7L

Le: 2.4 mH

BL: 16.5 NA

Qes: 0.56

Qms: 5.28

Qts: 0.52

Mms: 189.8 g

RMS: 400 Watts

Strato-12D4 – 2.5” voice coil – MAP $139.99

Re: 8.0 ohms

Fs: 31.3 Hz

VAS: 68.1 L

Le: 3.43 mH

BL: 20.9NA

Qes: 0.5

Qms: 4.23

Qts: 0.45

Mms: 138.7 g

RMS: 400 Watts

Strato-15D2 – 2.5” voice coil – MAP $159.99

Re: 4.0 ohms

Fs: 34,2 Hz

VAS: 20.2 L

Le: 1.75 mH

BL: 15.4 NA

Qes: 0.47

Qms: 4.43

Qts: 0.43

Mms: 130.9 g

RMS: 400 Watts

Strato-15D4 - 2.5” voice coil – MAP $159.99

Re: 8.0 ohms

Fs: 33,2 Hz

VAS: 111.5 L

Le: 3.5 mH

BL: 21.3 NA

Qes: 0.69

Qms: 5.02

Qts: 0.60

Mms: 187.1 g

RMS: 400 Watts

Strato-18D2 – 3” voice coil – MAP $189.99

Re: 4.0 ohms

Fs: 30.3 Hz

VAS: 205.1 L

Le: 2.01 mH

BL: 17.6 NAQes: 0.63

Qms: 6.76

Qts: 0.58

Mms: 254.5 g

RMS: 400 Watts

Strato-18D4 – 3” voice coil – MAP $189.99

Re: 8.0 ohms

Fs: 29.9 Hz

VAS: 187.2 L

Le: 2.38 mH

L: 20.4 NA

Qes: 0.78

Qms: 5.08

Qts: 0.68

Mms: 272.2 g

RMS: 400 Watts

Click to read more...



[av83 10+ year member]

I want to know more about the Exo...



[CHEMMINS 10+ year member]

Dats a lotta moofers!!!!!



[THATpurpleKUSH 5,000+ posts]

I'm digging the ultra low mms on those, lots of motor force to move those cones, these should be very efficient //content.invisioncic.com/y282845/emoticons/smile.gif.1ebc41e1811405b213edfc4622c41e27.gif



[cthedinger 10+ year member]

I want to know more about the Exo...

Info on the Exo will be ready around November. Right now we are waiting for the motors to be shipped. The parts just finished production and now are being shipped to the US.

Dats a lotta moofers!!!!!

//content.invisioncic.com/y282845/emoticons/smile.gif.1ebc41e1811405b213edfc4622c41e27.gif



[CAT MAN 5,000+ posts]

coleman i need big booty bish subs



[dbjunior 10+ year member]

What's in the background 12 spoke and crome motor



[cthedinger 10+ year member]

coleman i need big booty bish subs

Wait till you see the Exo finished in November //content.invisioncic.com/y282845/emoticons/wink.gif.608e3ea05f1a9f98611af0861652f8fb.gif

What's in the background 12 spoke and crome motor

Not sure. All the white baskets are Audio Technix subs. This thread is only about Audio Technix subs and products.



[dbjunior 10+ year member]

Wasn't sure was hoping it was sneek peak at a higher line something with a 3in coil. I take it these are from the build house not your warehouse.



[RAM_Designs 5,000+ posts]

What are those on the ground in the second picture?



[cthedinger 10+ year member]

Wasn't sure was hoping it was sneek peak at a higher line something with a 3in coil. I take it these are from the build house not your warehouse.

Correct. We have a 800w 3" coil sub in the works and have a 2000w 3" coil sub coming out in November. All our subs will have the white baskets/ black motor combo.

What are those on the ground in the second picture?

Strato 10"



[CHEMMINS 10+ year member]

Got any xmax numbers?



[naughtyca 10+ year member]

What's in the background 12 spoke and crome motor

yeah those subs looks nice, looks like double stacked magnets and motors looks beastly, are they yours?



[cthedinger 10+ year member]

Got any xmax numbers?

I will be posting them with the pre-order.

yeah those subs looks nice, looks like double stacked magnets and motors looks beastly, are they yours?

They are not mine as stated above. Mine are only the ones with the white baskets.
