Alpine MRV-F352.
5ch amp, old school quality, name brand, under rated. should do a good 50w rms around 13-14v on the highs. sub ch should do around 200w+ off 13-14v. hard to find amp, perfect for a small simple SQ setup.
full list of specs:
Power Output: RMS Continuous Power (at 14.4V, 20 Hz to 20 kHz) (CH1 – CH4)
Per channel into 4 ohms ......................................50W (0.08% THD)
Per channel into 2 ohms ......................................60W (0.3% THD)
Bridged into 4 ohms .....................................120W (0.3% THD)
Power Output: RMS Continuous Power (at 14.4V, 20 Hz) (CH5)
4 ohms ...................................................................150W (0.3% THD)
Max. Power (at 14.4V, 1 kHz) (CH1 – CH4)
Per channel into 4 ohms ..........................................75W (10% THD)
Max. Power (at 14.4V, 20 Hz) (CH5)
4 ohms ..............................................250W (10% THD)
Power Output: RMS Continuous Power (at 12.0V, 20 Hz to 20 kHz) (CH1 – CH4)
Per channel into 4 ohms .............................................30W (0.08% THD)
Per channel into 2 ohms ..........................................40W (0.3% THD)
Bridged into 4 ohms ..............................................80W (0.3% THD)
Power Output: RMS Continuous Power (at 12.0V, 20 Hz) (CH5)
4 ohms ..............................................100W (0.3% THD)
Frequency Response ......................................... 10 Hz to 50 kHz (+0, –1 dB)
Signal-to-Noise Ratio ......................................... 100 dBA (referenced to rated power)
Slew factor ..........................................................Greater than 5
Input Sensitivity (for rated power output)........... 200mV to 4.0V (1.0V at center detent)
Input Impedance ............................................ 10k ohms
Speaker Impedance ........................................ 4 or 2 ohms (Stereo), 4 ohms (Bridged)
Active Dividing Network Frequency and Slope ........... 50 to 200 Hz, 12 dB per octave
Power Requirement ........................................ 11 – 16VDC Negative Ground
Dimensions (W x H x D) .................................. 240mm x 53mm x 400mm (9-7/16" x 2-1/16" x 15-5/8")
Weight ............................................................5.0 kg (11 lbs.)
there's a couple small scrtaches here or there, otherwise in good condition considering the age. from what i could dig up this amp is approx 10-12 years old. and we all know they dont make them like they used to //content.invisioncic.com/y282845/emoticons/smile.gif.1ebc41e1811405b213edfc4622c41e27.gif 100% tested and working as it should.
new price, 120 shipped firm. plus i dont think youll find many 5ch's of this quality for the same price.
paypal is jaym_productions@yahoo.com, first come first serve.
manual located here if anyone wants to look through it:
http://narbi.free.fr/manuels/Amplis/Alpine/MRV-F352.pdf
5ch amp, old school quality, name brand, under rated. should do a good 50w rms around 13-14v on the highs. sub ch should do around 200w+ off 13-14v. hard to find amp, perfect for a small simple SQ setup.
full list of specs:
Power Output: RMS Continuous Power (at 14.4V, 20 Hz to 20 kHz) (CH1 – CH4)
Per channel into 4 ohms ......................................50W (0.08% THD)
Per channel into 2 ohms ......................................60W (0.3% THD)
Bridged into 4 ohms .....................................120W (0.3% THD)
Power Output: RMS Continuous Power (at 14.4V, 20 Hz) (CH5)
4 ohms ...................................................................150W (0.3% THD)
Max. Power (at 14.4V, 1 kHz) (CH1 – CH4)
Per channel into 4 ohms ..........................................75W (10% THD)
Max. Power (at 14.4V, 20 Hz) (CH5)
4 ohms ..............................................250W (10% THD)
Power Output: RMS Continuous Power (at 12.0V, 20 Hz to 20 kHz) (CH1 – CH4)
Per channel into 4 ohms .............................................30W (0.08% THD)
Per channel into 2 ohms ..........................................40W (0.3% THD)
Bridged into 4 ohms ..............................................80W (0.3% THD)
Power Output: RMS Continuous Power (at 12.0V, 20 Hz) (CH5)
4 ohms ..............................................100W (0.3% THD)
Frequency Response ......................................... 10 Hz to 50 kHz (+0, –1 dB)
Signal-to-Noise Ratio ......................................... 100 dBA (referenced to rated power)
Slew factor ..........................................................Greater than 5
Input Sensitivity (for rated power output)........... 200mV to 4.0V (1.0V at center detent)
Input Impedance ............................................ 10k ohms
Speaker Impedance ........................................ 4 or 2 ohms (Stereo), 4 ohms (Bridged)
Active Dividing Network Frequency and Slope ........... 50 to 200 Hz, 12 dB per octave
Power Requirement ........................................ 11 – 16VDC Negative Ground
Dimensions (W x H x D) .................................. 240mm x 53mm x 400mm (9-7/16" x 2-1/16" x 15-5/8")
Weight ............................................................5.0 kg (11 lbs.)
there's a couple small scrtaches here or there, otherwise in good condition considering the age. from what i could dig up this amp is approx 10-12 years old. and we all know they dont make them like they used to //content.invisioncic.com/y282845/emoticons/smile.gif.1ebc41e1811405b213edfc4622c41e27.gif 100% tested and working as it should.
new price, 120 shipped firm. plus i dont think youll find many 5ch's of this quality for the same price.
paypal is jaym_productions@yahoo.com, first come first serve.
manual located here if anyone wants to look through it:
http://narbi.free.fr/manuels/Amplis/Alpine/MRV-F352.pdf
