Specifications
What makes the TC-1000 The New Standard entry driver that practically blow's away what the retail competition offers at twice the price? Find out why the TC-1000 is the leader is high output below 200 dollars and still embarrasses whippy SQ drivers time and time again which can't match the TC-1000's distortion vs. SPL performance...
Advanced FEA Motor System
• Double stacked 1" tall ferrite magnets and bored T-yoke for long throw
• 135oz top grade magnet structure
• Anti-flux modulation copper shorting ring to lower distortion
• Low carbon steel used for the gap plate and t-yoke
• Pole vent for lower distortion and cooling capabilities.
Advanced high excursion soft part system
• High excursion 8.0" linear roll poly-cotton spider
• Intergraded woven leads to prevent lead-slap
• 2" diameter, 4-layer aluminum wire voice coil with an anodized aluminum former
• Single or dual 3.7Ω (4 ohm nominal) voice coil configuration
• Lightweight brushed and powder coated aluminum cone
• 1" wide long throw, highly durable NBR surround
• High quality thermal flexible epoxies to ensure longevity
Performance
• Effective motor force of 60 Newtons2 per watt (BL2/Re)
• 400 watts continuous power (1200 watts peak)
• 24mm BL XMax (voice coil, one-way)
• 37mm XMech (mechanically limited, one-way)
