Sold T3 t200 10"

[Redlineaudio 10+ year member]

I have a used T3 T200 10" sub in S4 The guy used it a few weeks and then traded it in on some other stuff.

$40 plus shipping for it.

Click to read more...



[my_stealth21 10+ year member]

No pics FTL



[Redlineaudio 10+ year member]

It looks a lot like a T3 T-200 in 10"

But I can get a pic tomorrow.



[Redlineaudio 10+ year member]

Pics



[Redlineaudio 10+ year member]

bump



[Redlineaudio 10+ year member]

bump



[Rich00 10+ year member]

Specs especially box recommendations and rms power.



[Redlineaudio 10+ year member]

T3 Audio T.200 Series Subwoofer - Sub, Speaker, Woofer, 10 inch, 12 inch, 400 watt, competition

Affordable Performance

The T.200 series subwoofers combine powerful bass and musical enjoyment at a very affordable price. Key features include high quality UV treated foam surrounds attached to non-pressed paper cones, stylish silk screened poly dust caps, 4 layer copper voice coils rated at 400 watts peak power handling, powder coated steel baskets, braided tinsel lead wires and a substantial FEA optimized 60 oz. motor assembly. Watching your budget will be no problem with our T.200 series as you're sure to get more performance for your hard earned dollars with features normally seen on much more expensive subwoofers.

Design

8”, 10” and 12” Subwoofers

Black anodized 60oz. motor structure

Durable pressed steel basket

Conex spider suspension

Heavy gauge tinsel leads

Treated foam surround

1 Piece poly front cap with logos

Single 4ohm voicecoil on 1.75” aluminum former

Copper round wire coil 20mm height

200w RMS/ 400w Peak

Parameters

T.200-8s T200-10s T-200-12s

Fs (Hz) 35 34 32

Qes 0.58 0.88 0.74

Qms 8.52 10.43 8.54

Qts 0.55 0.81 0.66

Vas (ft3) 0.64 0.84 1.76

Spl @ 1watt (dB) 85.45 86.45 87.58

X-max (Inches) 0.50 0.50 0.50

X-mechanical (inches) 1.00 1.00 1.00

Re (Ohms) 3.59 3.55 3.89

Pe (RMS Watts) 200 200 200

Piston Diam. (inches) 6.70 8.00 10

Sd ( in2) 36 50 78

BL 10 10 10

Le (mH) 1.72 1.72 1.81

Mms (grams) 65 95 128

Rms 1.93 2.32 2.42

Cms 240.4 161.59 138.35

Zmax (Ohms) 55.54 45.58 44.55

Specifications

T.200-8s T.200-10s T.200-12s

Total Weight (lbs) 6.5 7 8

Motor Weight (oz) 60 60 60

Mounting Depth 3.75" 4.60" 5.00"

Basket Depth 2.15" 3.00" 3.40"

Magnet Depth 1.60" 1.60" 1.60"

Cutout Diameter 7.10" 9.25" 11.20"

Overall Diameter 8.25" 10.30" 12.30"

Magnet Diameter 4.85" 4.85" 4.85"

Spider Diameter 5.50" 6.90" 7.50"

Coil Diameter 1.75" 1.75" 1.75"

Displacement (ft3) 0.03 0.05 0.07

Enclosures

T.200-8s T.200-10s T.200-12s

Sealed (ft3) 0.5 0.8 1

Vented (ft3) 0.75 1.1 1.5

Vent Diameter 3"/ 8in2 3"/ 8in2 3"/ 8in2

Vent Length 11" 13" 9"

Note: The enclosures recommended above are optimal size to suit the woofers for best overall performance. Enclosure sizes can vary depending on application. Using enclosure design software with the parameters provided with woofers is a good way to dial in woofers for users specific needs. ALL display room enclosures should be built 50% larger than optimal box recommendation for best open room performance.



[Redlineaudio 10+ year member]

bump



[Redlineaudio 10+ year member]

bump
