PLEASE?!?! Box Plans

[got_focus? 10+ year member]

As you can see here:

http://www.caraudio.com/forum/showthread.php?p=2859079#post2859079

I have been scammed by a member of the forum for a good amount of cash......which has left my paypal account negative $979

That being said, I can't pay via paypal, and after being scammed, I am not about to send a money order, check, or cash.....

So, I am asking for a free box plan..........

I have a focus with 2 SoundStream XXX15's running off a DD z1.

I need someone to design a box for me around 31hz. I don't need a cutout sheet, just need plans........

Anyone? Someone? //content.invisioncic.com/y282845/emoticons/crying.gif.ec0ebefe590df0251476573bc49e46d8.gif

Click to read more...



[mlstrass 5,000+ posts]

What cubic feet you shooting for? Max dimensions of box and displacement of subs?

I'll do one since I have family in Loveland. //content.invisioncic.com/y282845/emoticons/wink.gif.608e3ea05f1a9f98611af0861652f8fb.gif AWESOME place to live, plan on moving out there in 2-3 years.



[rpfuror 10+ year member]

ditto.. give us your max dimensions and what your tying to do and I can help.



[got_focus? 10+ year member]

you guys are awesome......

I was hoping someone could punch up the subs in BBP6 or something of the like and help me out....I was thinking something around 5.5 cubes net each

Max External Measurements:

18" Tall, Almost unlimited length (have like 5 feet), and 40.5" width

Subs forward, port rear



[wErd 5,000+ posts]

i have a focus too and the dimensions i came up with were 42" wide 20"high 21" depth...unless you have a hatch.



[got_focus? 10+ year member]

I have a hatch.....and no backseat //content.invisioncic.com/y282845/emoticons/biggrin.gif.d71a5d36fcbab170f2364c9f2e3946cb.gif



[mlstrass 5,000+ posts]

I did some research on those subs and 120+ ^2 of port was recommended. Is that number accurate?

Sent you a PM...



[rpfuror 10+ year member]

Ok, heres a design based on the specs that i could find for the drivers (fs,Qts,vb,xmax) it is 11.25 cu/ft @ 30hz... with top double baffle that allows you to use up to .40 cu/ft for bracing with out affecting the tuning that much. The port area is 120 sq/in and the design is based on 3/4 wood.

Have fun....

OLD DESIGN DELETED

BTW, you can put the subs / port on any face with a little manipulation.



[IonSQL 10+ year member]

Sides/front/back panels are going to have to be 15.75", not 16"... either that or the overall height is 18.25" instead of 18"

And I'd definitely move the subs to the other end of the top panel, closer to the port opening.



[got_focus? 10+ year member]

Ok, heres a design based on the specs that i could find for the drivers (fs,Qts,vb,xmax) it is 11.25 cu/ft @ 30hz... with top double baffle that allows you to use up to .40 cu/ft for bracing with out affecting the tuning that much. The port area is 120 sq/in and the design is based on 3/4 wood.
Have fun....

BTW, you can put the subs / port on any face with a little manipulation.

Can you change that around to subs forward?



[IonSQL 10+ year member]

Can you change that around to subs forward?

Not and have any decent amount of port area...



[RaiN 10+ year member]

Contact 80inches... Good guy, great boxes.



[rpfuror 10+ year member]

Sides/front/back panels are going to have to be 15.75", not 16"... either that or the overall height is 18.25" instead of 18"
And I'd definitely move the subs to the other end of the top panel, closer to the port opening.

Thats correct, I made changes after uploading the picture (I actually didn't notice I kept the dimensions on drawing)

also, like i stated the subs can be moved anywhere, I just put them there as a place holder.



[IonSQL 10+ year member]

also, like i stated the subs can be moved anywhere, I just put them there as a place holder.

I know, I was just giving my thoughts //content.invisioncic.com/y282845/emoticons/toast.gif.bc0657bf54b9ee653b6438524461341e.gif



[got_focus? 10+ year member]

Thats correct, I made changes after uploading the picture (I actually didn't notice I kept the dimensions on drawing)
also, like i stated the subs can be moved anywhere, I just put them there as a place holder.

Could you do subs forward port rear UP?



[rpfuror 10+ year member]

yea, it will be a little more complex.



[rpfuror 10+ year member]

Here you go man.. this is pretty much dead on 11 cu/ft @ 31hz w 120 sq/in of port.

Subs on the face port up... alot more to build.
