I am trying to help a friend with installing his kenwood head unit. It is a Z828/UF4, no matter what I look for online I cant seem to get the right wiring diagram. The 16 pin connector does not have a Red, Yellow, or Black wire. It has mixed colors I never seen before. I did notice when I was looking around that it looks like it may have came off a ford (but seems a little nice to be a stock ford radio).
Below is a list of how the wires go:
Pins 1-16
1. Black w/ Green Line
2. Green w/ Brown Line
3. Black w/ Purple Line
4. Dark Blue w/ Red Line
5,6,7,8 Skipped
9. White w/ Green Line
10. Orange w/ Red Line
11. Green w/ Brown Line
12. Purple w/ Pink Line
13. Light Blue w/ White Line
14. Brown w/ Yellow Line
15. Orange w/ Green Line
16. Gray w/ Blue Line
Any help will be greatly appriciated. Thanks agian for helping a newbie, lol. //content.invisioncic.com/y282845/emoticons/*******.gif.a649d21efc0d1fd4890a6428166586c1.gif
