Image dynamics ID!10v3d4 2 new 2 used

  • 4
    Participant count
  • Participant list

gentlejax
10+ year member

CarAudio.com Veteran
Item(s) for Sale:2 new in box idq10v3d4 and 2 used (1 has bad coil)



Dynamic Impact with the IDQ



The IDQ subwoofer series from Image Dynamics offers detailed and articulate accuracy at extreme volume levels. The ability to offer a dynamic impact without increasing the frequency extension makes them perfect for smaller enclosure sizes. IDQ series subwoofers are available in a 10" and 12" size and in a Dual 2 ohm or Dual 4 ohm version. With the ability to handle from 500 watts RMS to 750 watts RMS, makes these subwoofers perfect for the serious car audio enthusiast. Equipped with a mica-reinforced polypropylene wooofer cone and parabolic roll surround for durability and performance. The removable cone assembly allows for quick and easy servicing of the subwoofer whenever needed. The ability to custom match the basket color to your personal preference sets these woofers apart from any other, while adding a sense of self expression. So if you are looking for some bass that will really bump then the IDQ seirs by Image Dynamics is the way to go.



10" Dual 4 ohm IDQ V.3 Series Subwoofer

Power Handling:

Peak: 1000 watts

RMS: 500 watts

Recommended Power Range: 50-500 watts

Mica-reinforced polypropylene cone woofer

Parabolic roll surround

Removable core assembly for easy and quick replacement

Ability to custom match the basket color to your personal installation

Conex spider with integrated tinsel leads

Fiberglass composite basket

High-temperature aluminum voice coil

Proprietary voice coil attachment design

Also found as: IDQ10D4 V.3, IDQ10 D4 V.3, IDQ10 D4, IDQ10D4, IDQ10V.3 D4, IDQv3

Sensitivity: 85dB

Mounting depth: 5-3/4"

Cutout dimensions: 9-5/8"









Item(s) Description/Condition:









Price:





new ones $165 shipped 1 used good one $135 i needs repair $100 ?









Shipping and Miscellaneous Item Information:free









Item Pictures:













(List pictures in this section, 1st picture should be your username/date if you have less than 10 positive feedbacks with the i-Trader system or less than 10 references that you have sold to in the past. (These must be listed in your signature, or a link provided to a feedback thread listing these references)).


There are 4 subs total.

two new subs were still in the shipping box and never opened till me. have not been powered. the used ones had about 6 months use. I tested both. one reads fine (3.9ohms) the other reads good on one side and nothing on the other.

I intend to keep at least 1 working sub so once I sell a couple I may close this. Make an offer if you wish via pm


used one with bad coil $55 shipped

used one good $130 shipped

new one(s) $150 shipped

Subwoofer Specifications

Subwoofer Series IDQ V.3

Subwoofer Size 10"

Peak power Handling 1000 watts

RMS power Handling 500 watts

Voice Coil(s) Dual

Impedance (Per Voice Coil) 4 ohms

Sensitivity 85 dB

Xmax (millimeters) 17 mm

Subwoofer Design Round / Circle

Main Cone Color Black

Woofer Composition Mica Injected Polypropylene (MIPP)

Woofer Surround Parabolic Roll

Subwoofer Grille No

Re-Cone Kit Available No

Recommended Enclosure Specifications

Recommended Enclosure Type Ported / Vented

Sealed

Minimum Sealed Box Volume 0.55 cubic feet

Maximum Sealed Box Volume 1.10 cubic feet

Minimum Ported Box Volume 1.0 cubic feet

Maximum Ported Box Volume 1.50 cubic feet

Top-Mount Depth 5-3/4"

Cutout Diameter 9-5/8"


just installed the used one in a generic ported box. Its not tuned exactly right and the box is a tad small but seems to have as much output as my 12 inch Phoenix Gold Ti2 elite 12.

the PG 12 was in a sealed box where the IDQ10 is in a ported box thats not the proper size or tune.
