How do I BP this zrs c9

[calebkhill 10+ year member]

Want to BP my door speakers between 63hz and 3.5khz.

He re is a pic of my amp

Click to read more...



[av83 10+ year member]

you can't. you will need a two way crossover or an active hu



[calebkhill 10+ year member]

Why is there a BP filter there then.



[av83 10+ year member]

Why is there a BP filter there then.

because I'm an idiot. sorry, I can't see the pic you put up and I was going by fuzzy internetz pics.. I just read that it can bp by using the subsonic filter and lpf together. there should be a pdf download of the manual somewhere online that can guide you.



[calebkhill 10+ year member]

Ok. Yes it doesn't say in the manual. Knew there had to be a way though



[calebkhill 10+ year member]

Numb. Can someone look at this and figure out how to BP.

From an article at pasmag it says

a subsonic filter that can be used as the highpass section of a bandpass filter...



[vaiboy 10+ year member]

Numb. Can someone look at this and figure out how to BP.

From an article at pasmag it says

On channels 3&4 set the x-over switch to "LP/BP" set the subsonic dial to 63hz set the other switch to "x-10" and set the dial to 3.5khz. If you want channels 1&2 bandpassed too set the x-over switch to "Clone 3/4CH".



[calebkhill 10+ year member]

On channels 3&4 set the x-over switch to "LP/BP" set the subsonic dial to 63hz set the other switch to "x-10" and set the dial to 3.5khz. If you want channels 1&2 bandpassed too set the x-over switch to "Clone 3/4CH".

There it is. Thx. I figured that was it but yea that's it. How to determine how to set the frequency dead on is another thing...
