Ive had this oscope for a little while and its time to sell it.
Description from Velleman Inc.:
The Velleman Personal Scope is not a graphical multimeter but a complete portable oscilloscope at the size and the cost of a good multimeter. Its high sensitivity - down to 0.1mV/div - and extended scope functions make this unit ideal for hobby, service, automotive and development purposes. Because of its extreme value for money, the PersonalScope is well suited for educational use in schools and colleges. Suitable for measurements on audio equipment, mains voltage applications, digital signals, all kind of sensors, signal analysis in automotive applications, car stereo, etc… Its full auto setup function, makes measuring waveforms very easy.
Features
10MHz sampling rate
0.1mV sensitivity
up to 2MHz analogue bandwidth
5mV to 20V/div in 12 steps
200ns to 1hour/div time base in 32 steps
full auto set up
trigger mode: run, normal, once, roll, slope +/-
X and Y position signal shift
DVM readout with x10 option
audio power calculation (rms and peak)
dBm, dBV, DC, rms ... measurements
signal markers for Volt and Time
frequency readout (through markers)
recorder function (roll mode)
signal storage (2 memories)
LCD: 128x64 pixels / high-contrast
up to 20h on alkaline batteries
maximum size battery is 2000mA (bigger batteries will not fit)
optional:
practical holster: BAGHPS
handcase: CASEHPS
adapter 9V / 500mA: PS905USA
More...
Specifications
power supply: 5 x 1.5V AA battery or Nicd / NiMH (not incl.)
includes battery charging circuit
Files
oscilloscopes_cross_reference_uk.pdf
hps10.pdf
manual_hps40_10-uk.pdf
user manual (polisch)
The plastic case over the screen does have a small crack in it, which you can see in the pictures it does not affect its use AT ALL.
This oscope does need to be recalibrated which you can do yourself, there are tutorials online, i do not have the time to do it because im moving down to arkansas this weekend.
Comes with everything seen in picture (except Ann she never leaves my side for less than 200!)
As i was taking pics i noticed you couldnt see my name too well so i tossed in what im kind of known for the Ann Frank diary, if you feel scared about not seeing the name too well just look at all the threads ive started.
Also i have quite a few reps that will post on here.
Asking for 100 shipped obo.
