Austinw88
Senior VIP Member
Item(s) for Sale:
Soundstream XXX 15 Quad 1.2
Item(s) Description/Condition:
In good working condition, has 2 small scuffs on the surround but not all the way through. Has scratches on the motor but other wise good.
Nickel Plated 8 ga. Compression Wire Terminal
Non-Pressed UV Coated Paper
Flared Machined Pole Piece
Chrome Top & Bottom Plates
Die-Cast Aluminum Basket
Aluminum Voice Coil Former
Copper Clad Aluminum Voice Coil
UV Coated Foam Surround
Dual NOMEX Spiders
Suspension Integrated Tinsel Leads
T/S Specs
Fs (hz): 37.10
Qms: 3.910
Vas (ft.3): 2.239
Cms (mm/n): 0.078
Mms (g): 237.6
Rms (kg/s): 14.070
Xmax (mm): : 39.88
Xmech (mm): 59.82
Dia (in2): 12.220
Sd (in2): 117.30
Vd (ft.3): 0.160
Qes: 0.410
Re (Ohm): 4.80
Z (Ohm): 4
BL (Gauss): 25.39
Pe (watts): 8500
Qts: 0.370
NO: 0.760
1w/1m SPL (dB): 90.80
2.8v SPL (dB): 93.17
VC Dia. (in): 4.0
Impedance (Ohm): QVC 1
M-vd (ft.3): 0.2000
Measurements
Overall Diameter: 15.625
Overall Height: 11.375
Mounting Depth: 9.75
Cutout Diameter: 14
Motor Diameter: 11
Motor Height: 3.875
Flange Width: 0.75
Flange Height: 0.75
Weight (lb): 89
SPL Tuned Enclosure
Min. Vented (ft.3): 3.00
Port (dia. x length): (2)4x6.25
Fb (Hz): 49.76
F3 (Hz): 42.39
Opt. Vented (ft.3): 4.50
Port (dia. x length): (3)4x5.5
Fb (Hz): 50.26
F3 (Hz): 41.65
Max. Vented (ft.3): 6.00
Port (dia. x length): (4)4x5
Fb (Hz): 49.62
F3 (Hz): 40.77
Low Tuned Enclosure
Min. Vented (ft.3): 3.00
Port (dia. x length): (2)4x13
Fb (Hz): 39.92
F3 (Hz): 36.72
Opt. Vented (ft.3): 4.50
Port (dia. x length): (2)4x9.75
Fb (Hz): 34.91
F3 (Hz): 31.71
Max. Vented (ft.3): 6.00
Port (dia. x length): (3)4x17.5
Fb (Hz): 29.98
F3 (Hz): 28.02
Price:
350+shipping
Shipping and Miscellaneous Item Information:
on buyer
Item Pictures:
(List pictures in this section, 1st picture should be your username/date if you have less than 10 positive feedbacks with the i-Trader system or less than 10 references that you have sold to in the past. (These must be listed in your signature, or a link provided to a feedback thread listing these references)).
