Sold FS: SI Mag Claw 12" (pics!)

[PRIVATEpastry 10+ year member]

I bought this sub on the forums in July of this year, and I've had it installed in my ride until about 2 weeks ago. I have a cracked head gasket and I need to pay the bill... :-(

Anyways, onto the sub. Its a Stereo Integrity Magnum v1 with the coveted "claw" basket. SI hasn't sold this sub for some time. I'm not exactly sure on when they stopped producing it, but they only made a small number of them. If anyone knows the number, I'd appreciate it if ya chimed in! Point being, you're not going to find many of these in this good of condition, let alone ones that are up for sale.

Edit: SI only made 100 Mag Claws with the SI logo on the dustcap. (Thanks, hoss!)

Specs were pulled from the SI Mag v1 page.

T/S parameters:

Nominal Impedance: 2 Ohms per coil

Re: 3.6 Ohms (coils in series)

Fs: 32 Hz

Sd: 0.05 sqM

BL: 18.6 TM

SPL: 88.4 dB (1W/1M)

Qms: 4.05

Qes: .41

Qts: .37

Vas: 38.5 liters

Mms: 175.7 g

Mmd: 169.2 g

Cms: 108.5 uM/N

no: .43%

Xmax: 24 mm

Mechanical p-p: 2.6"

Power Handling: 900 watts RMS

Recommended Enclosures:

Sealed = 0.5 to 1.5 cubic feet.

Vented = 1.5 cubic feet tuned to 32 Hz, or 2.0 cubic feet tuned to 29 Hz.

The best two hobbies ever?

Spare gasket:

I purchased a brand new mounting gasket from SI for the sale of this sub. I had the sub mounted with the old gasket (seen in the last picture above) when it was installed in my car. I will include that gasket, if you would like it.

$219 + shipping

Click to read more...



[dalucifer 10+ year member]

Look at hoss's post..I could be wrong tho...Good Luck with this sale...This most likely my favorite sub of all time.



[hoss 5,000+ posts]

100 were made with the SI logo on them //content.invisioncic.com/y282845/emoticons/smile.gif.1ebc41e1811405b213edfc4622c41e27.gif



[saltyreefguy 10+ year member]

if the 950 is rms, would you know the max? is this si series 1 the better sounding sub from the other si model? also too bad you only have one for sale.



[coolahan 10+ year member]

****ing awesome.



[PRIVATEpastry 10+ year member]

100 were made with the SI logo on them //content.invisioncic.com/y282845/emoticons/smile.gif.1ebc41e1811405b213edfc4622c41e27.gif

Thanks!

if the 950 is rms, would you know the max? is this si series 1 the better sounding sub from the other si model? also too bad you only have one for sale.

I'm not sure what the max is, but I was sending it about 1100wrms daily and it never showed any signs of hurting. It sounded amazing. If I had to guess (correct me if I'm wrong, fellas) it could take about 1500wrms daily and more than that for burps.



[hoss 5,000+ posts]

1500 daily is probably about the max you would want to send it, but it should be fine with that. that is by far more than you would need though //content.invisioncic.com/y282845/emoticons/smile.gif.1ebc41e1811405b213edfc4622c41e27.gif

for burps, they could take upwards of 2k. hard to tell, but if you know what youre doing, you can send them alot of power safely //content.invisioncic.com/y282845/emoticons/smile.gif.1ebc41e1811405b213edfc4622c41e27.gif



[PRIVATEpastry 10+ year member]

Thanks for all the help, hoss. Bump.



[hoss 5,000+ posts]

no prob, i have alot of experience with claws //content.invisioncic.com/y282845/emoticons/smile.gif.1ebc41e1811405b213edfc4622c41e27.gif



[saltyreefguy 10+ year member]

any chance you might be able to get a second one?



[PRIVATEpastry 10+ year member]

any chance you might be able to get a second one?

Not likely, the single was hard enough to come by. If anyone else has one and is interested in selling it (not likely, but worth a shot), please chime in!

PM's replied, bump.



[PRIVATEpastry 10+ year member]

I got a question about the mark on the surround (left side) in the first picture. That was dust that I missed when I was cleaning the sub up. I noticed it when I posted the thread, and wiped it off. No, it isn't a scuff.



[HotCarl 10+ year member]

cool sub



[PRIVATEpastry 10+ year member]

Bump, quite a bit of interest so far. Not sold yet, though.



[PRIVATEpastry 10+ year member]

Bump
