Fluke 117 Electrician's Multimeter with Non-Contact voltage $125 Free Shipping (lower 48)
VoltAlert™ technology for non-contact voltage detection
AutoVolt automatic ac/dc voltage selection
Low input impedance: helps prevent false readings due to ghost voltage
Large white LED backlight to work in poorly lit areas
True-rms for accurate measurements on non-linear loads
Measures 10 A (20 A overload for 30-seconds)
Resistance, continuity, frequency and capacitance
Min/Max/Average with elapsed time to record signal fluctuations
Compact ergonomic design for one-handed operation
Compatible with optional magnetic hanger (ToolPak™) for hands free operation
CAT III 600 V safety rated
Extech 5MHz Dual Channel Multiscope 381295 Oscilloscope and Autoranging True RMS Digial MultiMeter $425 Free Shipping (lower 48)
This model (381295) is actually discontinued, but is better than the newer version (381295A). The only difference between the two models, is that the 381295 allows you to gather live data acquisition on to a computer via the RS-232 PC port, and the 381295A allows only saved frame shots to be uploaded on to a computer via a USB port. (Confirmed by a Extech Technician). You can call extech tech support if you chose to confirm this for yourself.
• Easy to Use Menu Driven Operation
• Internal or External Triggering
• Auto or Manual Setup for Horizontal and Vertical Scaling
• Single Shot Mode
• Window Freeze Locks Waveform in the Display
• Roll Mode for Slow Repetition Waveforms
• Store and Recall Up to 16 Waveforms and Setups
• Sampling Time: 25MS/s Dual Channel; 50MS/s Single Channel
• 132 x 128 Pixel Super-Twist Two Level Backlit Display
• Data Hold and Low Battery Indication
• Multimeter Functions Include AC/DC Voltage, Resistance, Continuity,
Frequency, RPM, Pulse Width, and % Duty Cycle
• RS-232 PC Interface and Software for Transferring Waveforms and Data
Specifications: Oscilloscope
Bandwidth 5MHz
Max. Sample Rate per Channel 25MS/s (dual channel); 50MS/s (single channel)
Record Length 512 single shot; 256 all other modes
Sample Mode Single shot, Roll, Normal
Max Vertical Sensitivity 50mV
Max Input Voltage 600V DC or AC rms
Trigger Modes Auto, Normal, Single
Trigger Source Channel A, Channel B, External
Trigger Coupling AC, DC
Timebase 1?S to 5S
Input Impedance 1M½
Specifications: Multimeter
DC Voltage 0.001V to 1000V (0.3% basic accuracy)
AC Voltage (TRMS) 0.001 to 750V (50-20kHz bandwidth)
Resistance 0.001k½ to 5M½
Continuity Test voltage 1.7V; threshold 100 digits
Frequency 0.01Hz to 10MHz
RPM 240-60,000
Pulse Width 2?s to 500ms
Duty Cycle 25% to 75%
Dimensions 7.7x3.5x1.6” (195x90x40mm)
Weight 16.2oz (260g)
Power 4.8V Ni-MH Battery/120V 60Hz adaptor/charger
