..........Clamped the XXV-Colossus....

[Ali1 10+ year member]

Many people have asked if these amps were overrated, while other individuals have criticized it based on its price to power ratio. I recently clamped the Colossus on a 36hz tone and these were my results ......

102.4 ac volts

29.2 ac amps

102.4 X 29.2 = 2990.08 RMS (voltage dropped to 12.13)

102.4ac / 29.2 = 3.506 ohms

2990 @ 3.5ohms with only 12.13v (weak electrical)

I am pleased with these results and happy i chose this amp. Will be getting my hands on bxi2608 hopefully to test its ratings....

Comments/Criticisms are welcome......

Click to read more...



[profundus-sanus 10+ year member]

how was distortion factored into this?



[kombat96 10+ year member]

get some pics up lets see the monster



[Ali1 10+ year member]

get some pics up lets see the monster

how was distortion factored into this?

head unit was turned a tad under 3/4. Anything over 3 quarters, and the distortion became audible.

gain on the amplifier was set to 2v, which is roughly 3 quarters. Clipping indicator never came up throughout the test. bass boost off.



[audioarsonal 10+ year member]

What was the begining voltage?Was this with the vehicle on or off?What is the DCR ohms?



[Redlineaudio 10+ year member]

Nice power at almost 4 ohms.



[Tom Gralewski 10+ year member]

Nice power at almost 4 ohms.

x2



[req 5,000+ posts]

just a FYI since not everyone knows the ratings of this thing;

http://www.sonicelectronix.com/item_9356_Hifonics+XXV-COLOSSUS.html

2200 watts x 1 @ 4 ohms bridged



[profundus-sanus 10+ year member]

you should try different frequencies to see what it does @ 2 ohms.



[cleansoundzz 10+ year member]

Are you going to test out a BXI 1608 as well? That would be good.



[Ali1 10+ year member]

What was the begining voltage?Was this with the vehicle on or off?What is the DCR ohms?

Car on.

beginning voltage 14.1

haven't checked DCR. nominal 2ohms wired to 1ohm each channel



[Ali1 10+ year member]

you should try different frequencies to see what it does @ 2 ohms.

Will do when i have more free time



[rain377 10+ year member]

i just got one of these amps too. i have it on 2-15" bl and it pounds the hell out of them. awesome amp for the money.



[Ali1 10+ year member]

you geting the same result I am?



[Team Maxxsonics 10+ year member]

Get the load down to 2-Ohms and you will se a pretty substantial power gain.

Drop that amp down to 1-1.4-Ohms for a burp and hold on to your socks //content.invisioncic.com/y282845/emoticons/wink.gif.608e3ea05f1a9f98611af0861652f8fb.gif

The amp is very efficient and will most certainly produce a lot more power then indicated in the manual.
